SUN HYDRAULICS
DDDGXON
$182.77 USD
- SUN HYDRAULICS
- Material:DDDGXON
- Model:DDDG-XON
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDGXON (DDDGXON) is a high-performance, two-position, 3-way directional cartridge valve designed for advanced hydraulic systems. This model features a unique six-port configuration, although port 5 remains unused, allowing for versatile application across various hydraulic circuits. With the capacity to handle pressures up to 5000 psi (350 bar), the DDDGXON is suitable for heavy-duty operations. The valve offers multiple spool configurations, enhancing its adaptability to different system requirements. The performance of these pilot-to-shift valves varies depending on the spool type selected, ensuring tailored solutions for specific applications. Additionally, the DDDGXON boasts a hardened spool and sleeve which not only reduce leakage rates but also extend the valve's life by resisting wear. Sun Hydraulics has incorporated its floating style construction into this model, minimizing potential internal binding that can occur due to installation torque or variations in cavity-cartridge machining. This feature significantly enhances reliability and maintenance ease. The valve can manage a flow capacity of up to 20 gpm (80 L/min) and requires a minimum pilot pressure of 145 psi (10 bar) to shift, with full shifting achievable at 290 psi (20 bar) under rated flow conditions. For installation purposes, the valve has specific requirements including a hex size of 1-1/8 inches (28.6 mm) and an installation torque between 45 - 50 lbf.ft (61 - 68 Nm). The DDDGXON uses Viton seals for enhanced performance under various operating conditions. This model exemplifies robust design combined with functional flexibility, making it ideal for sophisticated hydraulic applications where efficiency and durability are paramount.
The Sun Hydraulics DDDGXON (DDDGXON) is a high-performance, two-position, 3-way directional cartridge valve designed for advanced hydraulic systems. This model features a unique six-port configuration, although port 5 remains unused, allowing for versatile application across various hydraulic circuits. With the capacity to handle pressures up to 5000 psi (350 bar), the DDDGXON is suitable for heavy-duty operations. The valve offers multiple spool configurations, enhancing its adaptability to different system requirements. The performance of these pilot-to-shift valves varies depending on the spool type selected, ensuring tailored solutions for specific applications. Additionally, the DDDGXON boasts a hardened spool and sleeve which not only reduce leakage rates but also extend the valve's life by resisting wear. Sun Hydraulics has incorporated its floating style construction into this model, minimizing potential internal binding that can occur due to installation torque or variations in cavity-cartridge machining. This feature significantly enhances reliability and maintenance ease. The valve can manage a flow capacity of up to 20 gpm (80 L/min) and requires a minimum pilot pressure of 145 psi (10 bar) to shift, with full shifting achievable at 290 psi (20 bar) under rated flow conditions. For installation purposes, the valve has specific requirements including a hex size of 1-1/8 inches (28.6 mm) and an installation torque between 45 - 50 lbf.ft (61 - 68 Nm). The DDDGXON uses Viton seals for enhanced performance under various operating conditions. This model exemplifies robust design combined with functional flexibility, making it ideal for sophisticated hydraulic applications where efficiency and durability are paramount.
Two-position, 3-way directional cartridges are 6-port (port 5 is not used) directional valves that can be configured with up to 5 different spool configurations. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- Leakage listed in technical data is for each path.
- Pressure at port 6 directly opposes port 1.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-52A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 145 psi10 bar |
| Pilot Pressure Required for Full Shift at Rated Flow | 290 psi20 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-052-006 |
