SUN HYDRAULICS
DDDGXOV
$193.70 USD
- SUN HYDRAULICS
- Material:DDDGXOV
- Model:DDDG-XOV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDDGXOV (DDDGXOV) is a high-performance two-position, 3-way directional cartridge valve designed for robust hydraulic system applications. With its six-port configuration (port 5 unused), it offers versatile connection possibilities and can support up to five different spool configurations. This model is engineered to handle a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of 20 gpm (80 L/min). The valve features a hardened spool and sleeve which ensure low leakage rates and superior wear characteristics, critical for maintaining efficiency and longevity in demanding environments. The DDDGXOV incorporates Sun's innovative floating style construction, which significantly reduces the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This design enhancement promotes reliable operation and ease of maintenance. The valve requires a minimum pilot pressure of 145 psi (10 bar) to shift, with full shifting achieved at 290 psi (20 bar) under rated flow conditions. Leakage performance is optimized, with maximum valve leakage specified at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Installation specifications include a hex size of 1-1/8 inches (28.6 mm) and an installation torque range between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm), ensuring secure fitting without over-torquing. The DDDGXOV uses Viton seals for enhanced temperature and chemical resistance, making it suitable for a variety of fluid media within hydraulic systems. This model is ideal for applications requiring precise control over direction and flow within hydraulic circuits, demonstrating both reliability and versatility in its operational capabilities.
The Sun Hydraulics DDDGXOV (DDDGXOV) is a high-performance two-position, 3-way directional cartridge valve designed for robust hydraulic system applications. With its six-port configuration (port 5 unused), it offers versatile connection possibilities and can support up to five different spool configurations. This model is engineered to handle a maximum operating pressure of 5000 psi (350 bar) and has a flow capacity of 20 gpm (80 L/min). The valve features a hardened spool and sleeve which ensure low leakage rates and superior wear characteristics, critical for maintaining efficiency and longevity in demanding environments. The DDDGXOV incorporates Sun's innovative floating style construction, which significantly reduces the risk of internal parts binding\u2014a common issue caused by excessive installation torque or variations in cavity/cartridge machining. This design enhancement promotes reliable operation and ease of maintenance. The valve requires a minimum pilot pressure of 145 psi (10 bar) to shift, with full shifting achieved at 290 psi (20 bar) under rated flow conditions. Leakage performance is optimized, with maximum valve leakage specified at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). Installation specifications include a hex size of 1-1/8 inches (28.6 mm) and an installation torque range between 45 \u2013 50 lbf\u00b7ft (61 \u2013 68 Nm), ensuring secure fitting without over-torquing. The DDDGXOV uses Viton seals for enhanced temperature and chemical resistance, making it suitable for a variety of fluid media within hydraulic systems. This model is ideal for applications requiring precise control over direction and flow within hydraulic circuits, demonstrating both reliability and versatility in its operational capabilities.
Two-position, 3-way directional cartridges are 6-port (port 5 is not used) directional valves that can be configured with up to 5 different spool configurations. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- Leakage listed in technical data is for each path.
- Pressure at port 6 directly opposes port 1.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-52A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 145 psi10 bar |
| Pilot Pressure Required for Full Shift at Rated Flow | 290 psi20 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Pilot Volume Displacement | .05 in³0,82 cc |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-052-006 |
