SUN HYDRAULICS
DDFCXCV
$339.64 USD
- SUN HYDRAULICS
- Material:DDFCXCV
- Model:DDFC-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDFCXCV (DDFCXCV) is a high-performance, three-position, 4-way directional cartridge valve designed for advanced hydraulic systems. This model features a spring-centered mechanism and includes six ports with the capability to handle up to 5000 psi (350 bar). The valve's design incorporates hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics, enhancing its durability and reliability in demanding applications. Equipped with Sun's innovative floating style construction, the DDFCXCV minimizes internal parts binding which could result from excessive installation torque or variations in cavity-cartridge machining. This feature helps in maintaining consistent performance and prolongs the lifespan of the valve under various operational conditions. The DDFCXCV operates within a maximum flow capacity of 40 gpm (160 L/min) and requires a minimum pilot pressure of 200 psi (14 bar) to shift the valve effectively. It also features a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure applications. With a leakage rate specified at 10 in\u00b3/min per 1000 psi (160 cc/min per 70 bar), this model ensures efficient operation with minimal fluid loss. This valve is designed with a hex size of 1\u00bc inches (31.8 mm) and requires an installation torque between 150-160 lbf\u00b7ft (203-217 Nm). The DDFCXCV uses Viton seals (part number: 990053006) for enhanced sealing capabilities, ensuring reliable performance across various temperature ranges and environmental conditions. This model is ideal for hydraulic systems requiring precise control over direction and flow, suitable for both mobile and industrial applications.
The Sun Hydraulics DDFCXCV (DDFCXCV) is a high-performance, three-position, 4-way directional cartridge valve designed for advanced hydraulic systems. This model features a spring-centered mechanism and includes six ports with the capability to handle up to 5000 psi (350 bar). The valve's design incorporates hardened spool and sleeve components that ensure low leakage rates and superior wear characteristics, enhancing its durability and reliability in demanding applications. Equipped with Sun's innovative floating style construction, the DDFCXCV minimizes internal parts binding which could result from excessive installation torque or variations in cavity-cartridge machining. This feature helps in maintaining consistent performance and prolongs the lifespan of the valve under various operational conditions. The DDFCXCV operates within a maximum flow capacity of 40 gpm (160 L/min) and requires a minimum pilot pressure of 200 psi (14 bar) to shift the valve effectively. It also features a maximum operating pressure of 5000 psi (350 bar), making it suitable for high-pressure applications. With a leakage rate specified at 10 in\u00b3/min per 1000 psi (160 cc/min per 70 bar), this model ensures efficient operation with minimal fluid loss. This valve is designed with a hex size of 1\u00bc inches (31.8 mm) and requires an installation torque between 150-160 lbf\u00b7ft (203-217 Nm). The DDFCXCV uses Viton seals (part number: 990053006) for enhanced sealing capabilities, ensuring reliable performance across various temperature ranges and environmental conditions. This model is ideal for hydraulic systems requiring precise control over direction and flow, suitable for both mobile and industrial applications.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-53A |
| Series | 3 |
| Capacity | 40 gpm160 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 200 psi14 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 in³/min.@1000 psi160 cc/min.@70 bar |
| Pilot Volume Displacement | .11 in³1,8 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-053-006 |
