SUN HYDRAULICS
DDFCXDV
$349.57 USD
- SUN HYDRAULICS
- Material:DDFCXDV
- Model:DDFC-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDFCXDV (DDFCXDV) is a high-performance hydraulic valve designed for robust fluid control in various applications. This three-position, 4-way directional cartridge valve is spring-centered and features a six-port configuration, providing flexible installation options and operational capabilities. The valve operates with a maximum capacity of 40 gpm (160 L/min), making it suitable for systems requiring high flow rates. Constructed to handle a maximum operating pressure of 5000 psi (350 bar), all ports, including the x and y pilot ports (port 1 and port 6), are designed to accommodate this pressure level. This ensures the valve can be used in high-pressure environments consistently without performance degradation. The minimum pilot pressure required to shift the valve is set at 200 psi (14 bar), offering precise control over the shifting operations. The DDFCXDV incorporates hardened spool and sleeve components which not only reduce leakage but also extend the wear life of the valve, ensuring reliable operation and minimal maintenance requirements. The leakage specification per path, including pilot paths, is meticulously maintained at 10 in\u00b3/min at 1000 psi (160 cc/min at 70 bar). Additionally, the valve features Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or cavity/cartridge machining variations. For installation, the valve has a hex size of 1\u00bc inch (31.8 mm) and requires an installation torque between 150-160 lbf\u00b7ft (203-217 Nm). Moreover, it uses Viton seals for enhanced durability against fluid corrosiveness and temperature variations. This model\u2019s robust build and versatile design make it an excellent choice for demanding hydraulic applications requiring reliable directional control and high-pressure operation.
The Sun Hydraulics DDFCXDV (DDFCXDV) is a high-performance hydraulic valve designed for robust fluid control in various applications. This three-position, 4-way directional cartridge valve is spring-centered and features a six-port configuration, providing flexible installation options and operational capabilities. The valve operates with a maximum capacity of 40 gpm (160 L/min), making it suitable for systems requiring high flow rates. Constructed to handle a maximum operating pressure of 5000 psi (350 bar), all ports, including the x and y pilot ports (port 1 and port 6), are designed to accommodate this pressure level. This ensures the valve can be used in high-pressure environments consistently without performance degradation. The minimum pilot pressure required to shift the valve is set at 200 psi (14 bar), offering precise control over the shifting operations. The DDFCXDV incorporates hardened spool and sleeve components which not only reduce leakage but also extend the wear life of the valve, ensuring reliable operation and minimal maintenance requirements. The leakage specification per path, including pilot paths, is meticulously maintained at 10 in\u00b3/min at 1000 psi (160 cc/min at 70 bar). Additionally, the valve features Sun's floating style construction which minimizes internal parts binding\u2014a common issue caused by excessive installation torque or cavity/cartridge machining variations. For installation, the valve has a hex size of 1\u00bc inch (31.8 mm) and requires an installation torque between 150-160 lbf\u00b7ft (203-217 Nm). Moreover, it uses Viton seals for enhanced durability against fluid corrosiveness and temperature variations. This model\u2019s robust build and versatile design make it an excellent choice for demanding hydraulic applications requiring reliable directional control and high-pressure operation.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-53A |
| Series | 3 |
| Capacity | 40 gpm160 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 200 psi14 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 in³/min.@1000 psi160 cc/min.@70 bar |
| Pilot Volume Displacement | .11 in³1,8 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-053-006 |
