SUN HYDRAULICS
DDFCXRV
$344.60 USD
- SUN HYDRAULICS
- Material:DDFCXRV
- Model:DDFC-XRV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDFCXRV (DDFCXRV) is a high-performance hydraulic valve designed for robust and precise fluid control in various applications. This three-position, 4-way directional cartridge valve features a spring-centered configuration and six ports, including the supply port designated as port 3. Each port, including the x and y pilot ports (port 1 and port 6), can withstand pressures up to 5000 psi (350 bar), making the valve suitable for high-pressure systems. The DDFCXRV model offers a flow capacity of up to 40 gpm (160 L/min) and requires a minimum pilot pressure of 200 psi (14 bar) to shift the valve effectively. It operates at a maximum pressure of 5000 psi (350 bar), ensuring reliable performance under demanding conditions. The valve's design minimizes leakage, with a maximum rate specified at 10 in\u00b3/min at 1000 psi (160 cc/min at 70 bar), reflecting its efficiency in maintaining system integrity. Constructed with a hardened spool and sleeve, the DDFCXRV ensures low spool leakage rates and exhibits excellent wear characteristics, extending the valve's operational life. Additionally, it incorporates Sun\u2019s floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This valve is compatible with Viton seal kits (part number: 990053006), ensuring effective sealing and chemical resistance across various operating conditions. The hex size for installation is specified at 1\u00bc inches (31.8 mm) with an installation torque range between 150 -160 lbf\u00b7ft (203 -217 Nm), facilitating secure and straightforward installation. Overall, the Sun Hydraulics DDFCXRV offers reliable performance for hydraulic systems requiring precise directional control and robust handling of high pressures.
The Sun Hydraulics DDFCXRV (DDFCXRV) is a high-performance hydraulic valve designed for robust and precise fluid control in various applications. This three-position, 4-way directional cartridge valve features a spring-centered configuration and six ports, including the supply port designated as port 3. Each port, including the x and y pilot ports (port 1 and port 6), can withstand pressures up to 5000 psi (350 bar), making the valve suitable for high-pressure systems. The DDFCXRV model offers a flow capacity of up to 40 gpm (160 L/min) and requires a minimum pilot pressure of 200 psi (14 bar) to shift the valve effectively. It operates at a maximum pressure of 5000 psi (350 bar), ensuring reliable performance under demanding conditions. The valve's design minimizes leakage, with a maximum rate specified at 10 in\u00b3/min at 1000 psi (160 cc/min at 70 bar), reflecting its efficiency in maintaining system integrity. Constructed with a hardened spool and sleeve, the DDFCXRV ensures low spool leakage rates and exhibits excellent wear characteristics, extending the valve's operational life. Additionally, it incorporates Sun\u2019s floating style construction which helps prevent internal parts from binding due to excessive installation torque or variations in cavity/cartridge machining. This valve is compatible with Viton seal kits (part number: 990053006), ensuring effective sealing and chemical resistance across various operating conditions. The hex size for installation is specified at 1\u00bc inches (31.8 mm) with an installation torque range between 150 -160 lbf\u00b7ft (203 -217 Nm), facilitating secure and straightforward installation. Overall, the Sun Hydraulics DDFCXRV offers reliable performance for hydraulic systems requiring precise directional control and robust handling of high pressures.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-53A |
| Series | 3 |
| Capacity | 40 gpm160 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 200 psi14 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 in³/min.@1000 psi160 cc/min.@70 bar |
| Pilot Volume Displacement | .11 in³1,8 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-053-006 |
