SUN HYDRAULICS
DDFCXWV
$348.57 USD
- SUN HYDRAULICS
- Material:DDFCXWV
- Model:DDFC-XWV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDFCXWV (DDFCXWV) is a versatile three-position, 4-way directional cartridge valve, engineered for high-performance hydraulic systems. This model is spring-centered and features a six-port configuration with a designated supply port at port 3. Each port, including the x and y pilot ports (port 1 and port 6), can withstand pressures up to 5000 psi (350 bar). The DDFCXWV\u2019s performance capabilities depend on the specific spool type chosen, allowing customization based on application needs. This valve boasts a maximum capacity of 40 gpm (160 L/min) and requires a minimum pilot pressure of 200 psi (14 bar) to shift the valve effectively. It is designed to operate at a maximum pressure of 5000 psi (350 bar). The leakage specifications for this model are meticulously detailed in the technical data, indicating leakage per path including pilot paths, with maximum valve leakage noted at 10 in\u00b3/min at 1000 psi (160 cc/min at 70 bar). Sun Hydraulics has incorporated their floating style construction into the DDFCXWV model which helps minimize internal parts binding that could occur due to excessive installation torque or variations in cavity/cartridge machining. This design feature, along with a hardened spool and sleeve, ensures consistent low spool leakage rates and enhances the durability of the valve under demanding conditions. The physical specifications include a valve hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150 \u2013 160 lbf\u00b7ft (203 \u2013 217 Nm). For maintenance or repairs, Viton seal kits are available under part number: 990053006. This robust construction and thoughtful engineering make the DDFCXWV an ideal choice for applications requiring reliable directional control in hydraulic systems.
The Sun Hydraulics DDFCXWV (DDFCXWV) is a versatile three-position, 4-way directional cartridge valve, engineered for high-performance hydraulic systems. This model is spring-centered and features a six-port configuration with a designated supply port at port 3. Each port, including the x and y pilot ports (port 1 and port 6), can withstand pressures up to 5000 psi (350 bar). The DDFCXWV\u2019s performance capabilities depend on the specific spool type chosen, allowing customization based on application needs. This valve boasts a maximum capacity of 40 gpm (160 L/min) and requires a minimum pilot pressure of 200 psi (14 bar) to shift the valve effectively. It is designed to operate at a maximum pressure of 5000 psi (350 bar). The leakage specifications for this model are meticulously detailed in the technical data, indicating leakage per path including pilot paths, with maximum valve leakage noted at 10 in\u00b3/min at 1000 psi (160 cc/min at 70 bar). Sun Hydraulics has incorporated their floating style construction into the DDFCXWV model which helps minimize internal parts binding that could occur due to excessive installation torque or variations in cavity/cartridge machining. This design feature, along with a hardened spool and sleeve, ensures consistent low spool leakage rates and enhances the durability of the valve under demanding conditions. The physical specifications include a valve hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150 \u2013 160 lbf\u00b7ft (203 \u2013 217 Nm). For maintenance or repairs, Viton seal kits are available under part number: 990053006. This robust construction and thoughtful engineering make the DDFCXWV an ideal choice for applications requiring reliable directional control in hydraulic systems.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-53A |
| Series | 3 |
| Capacity | 40 gpm160 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 200 psi14 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 in³/min.@1000 psi160 cc/min.@70 bar |
| Pilot Volume Displacement | .11 in³1,8 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-053-006 |
