SUN HYDRAULICS
DDFCXYN
$328.72 USD
- SUN HYDRAULICS
- Material:DDFCXYN
- Model:DDFC-XYN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDFCXYN (DDFCXYN) is a robust and versatile hydraulic valve designed for demanding applications. This three-position, 4-way directional cartridge valve is spring-centered and features a 6-port configuration. It is suitable for use in systems requiring pilot-to-shift operation, with the capability to handle a maximum operating pressure of 5000 psi (350 bar). The valve offers a flow capacity of up to 40 gpm (160 L/min), making it ideal for various hydraulic functions. Each port on the DDFCXYN, including the X and Y pilot ports (port 1 and port 6), can withstand the full operating pressure, ensuring reliability under high-pressure conditions. The minimum pilot pressure required to shift the valve is 200 psi (14 bar), which facilitates flexible control options for different system requirements. Additionally, this model boasts hardened spool and sleeve components that not only reduce spool leakage rates but also enhance wear characteristics, thereby extending the valve's operational life. Sun Hydraulics has incorporated its patented floating style construction into the DDFCXYN model. This design feature minimizes internal parts binding that could occur due to excessive installation torque or variations in cavity-cartridge machining, thus ensuring consistent performance and durability. The valve's hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150 -160 lbf-ft (203 -217 Nm). Overall, the Sun Hydraulics DDFCXYN offers high reliability and performance for hydraulic systems requiring precise control with high pressure tolerance. Its advanced design features make it a preferred choice in various applications where durability and operational integrity are critical.
The Sun Hydraulics DDFCXYN (DDFCXYN) is a robust and versatile hydraulic valve designed for demanding applications. This three-position, 4-way directional cartridge valve is spring-centered and features a 6-port configuration. It is suitable for use in systems requiring pilot-to-shift operation, with the capability to handle a maximum operating pressure of 5000 psi (350 bar). The valve offers a flow capacity of up to 40 gpm (160 L/min), making it ideal for various hydraulic functions. Each port on the DDFCXYN, including the X and Y pilot ports (port 1 and port 6), can withstand the full operating pressure, ensuring reliability under high-pressure conditions. The minimum pilot pressure required to shift the valve is 200 psi (14 bar), which facilitates flexible control options for different system requirements. Additionally, this model boasts hardened spool and sleeve components that not only reduce spool leakage rates but also enhance wear characteristics, thereby extending the valve's operational life. Sun Hydraulics has incorporated its patented floating style construction into the DDFCXYN model. This design feature minimizes internal parts binding that could occur due to excessive installation torque or variations in cavity-cartridge machining, thus ensuring consistent performance and durability. The valve's hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150 -160 lbf-ft (203 -217 Nm). Overall, the Sun Hydraulics DDFCXYN offers high reliability and performance for hydraulic systems requiring precise control with high pressure tolerance. Its advanced design features make it a preferred choice in various applications where durability and operational integrity are critical.
Three-position, 4-way directional cartridges are spring-centered, 6-port directional valves that can be configured from a choice of spool options. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- All ports will accept 5000 psi (350 bar), including the x and y pilot ports (port 1 and port 6).
- Leakage listed in technical data is for each path, including pilot paths.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-53A |
| Series | 3 |
| Capacity | 40 gpm160 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 200 psi14 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 in³/min.@1000 psi160 cc/min.@70 bar |
| Pilot Volume Displacement | .11 in³1,8 cc |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-053-006 |
