SUN HYDRAULICS
DDHGXOV
$581.28 USD
- SUN HYDRAULICS
- Material:DDHGXOV
- Model:DDHG-XOV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDHGXOV (DDHGXOV) is a high-performance, two-position, 3-way directional cartridge valve designed for robust hydraulic system applications. This model, which falls under the T-54A cavity and Series 4 category, supports a maximum flow capacity of 80 gpm (320 L/min) and can handle pressures up to 5000 psi (350 bar). The valve features six ports with port 5 being inactive, and it offers up to five different spool configurations tailored to specific operational requirements. Each spool type determines the overall capacity of these pilot-to-shift valves, making them versatile for various hydraulic functions. The design incorporates a hardened spool and sleeve that not only ensure minimal leakage rates but also provide excellent wear characteristics. This durability is enhanced by Sun's floating style construction that reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. Key specifications include a minimum pilot pressure requirement of 300 psi (20 bar) for valve shifting and 350 psi (24 bar) for full shift at rated flow. The maximum leakage at optimal conditions is quantified at 3 in\u00b3/min at 1000 psi (50 cc/min at 70 bar). Installation requires a specific torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm), and the valve's hex size is standardized at 1-5/8 inches (41.3 mm). Weighing in at approximately 5.9 lbs (2.7 kg), this model ensures reliable performance in demanding environments where hydraulic precision and stability are paramount.
The Sun Hydraulics DDHGXOV (DDHGXOV) is a high-performance, two-position, 3-way directional cartridge valve designed for robust hydraulic system applications. This model, which falls under the T-54A cavity and Series 4 category, supports a maximum flow capacity of 80 gpm (320 L/min) and can handle pressures up to 5000 psi (350 bar). The valve features six ports with port 5 being inactive, and it offers up to five different spool configurations tailored to specific operational requirements. Each spool type determines the overall capacity of these pilot-to-shift valves, making them versatile for various hydraulic functions. The design incorporates a hardened spool and sleeve that not only ensure minimal leakage rates but also provide excellent wear characteristics. This durability is enhanced by Sun's floating style construction that reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. Key specifications include a minimum pilot pressure requirement of 300 psi (20 bar) for valve shifting and 350 psi (24 bar) for full shift at rated flow. The maximum leakage at optimal conditions is quantified at 3 in\u00b3/min at 1000 psi (50 cc/min at 70 bar). Installation requires a specific torque range between 350 \u2013 375 lbf\u00b7ft (474 \u2013 508 Nm), and the valve's hex size is standardized at 1-5/8 inches (41.3 mm). Weighing in at approximately 5.9 lbs (2.7 kg), this model ensures reliable performance in demanding environments where hydraulic precision and stability are paramount.
Two-position, 3-way directional cartridges are 6-port (port 5 is not used) directional valves that can be configured with up to 5 different spool configurations. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- Leakage listed in technical data is for each path.
- Pressure at port 6 directly opposes port 1.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-54A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 300 psi20 bar |
| Pilot Pressure Required for Full Shift at Rated Flow | 350 psi24 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 3 in³/min.@1000 psi50 cc/min.@70 bar |
| Pilot Volume Displacement | .27 in³4,4 cc |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 5.9 lb2,7 kg |
| Seal kit - Cartridge | Viton: 990-054-006 |
