SUN HYDRAULICS
DDHGXYV
$590.22 USD
- SUN HYDRAULICS
- Material:DDHGXYV
- Model:DDHG-XYV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DDHGXYV (DDHGXYV) is a high-performance, two-position, 3-way directional cartridge valve. This model is versatile with its six ports, although port 5 is not utilized. It can be configured in up to five different spool configurations according to specific application needs. The supply port for this model is designated as port 3, and all ports are capable of handling a maximum operating pressure of 5000 psi (350 bar). The valve's performance and capacity vary depending on the spool type specified. Key features of the DDHGXYV include a hardened spool and sleeve that ensure low leakage rates and superior wear characteristics, essential for maintaining efficiency and longevity in demanding environments. Additionally, the valve incorporates Sun's floating style construction which minimizes internal part binding\u2014a common issue resulting from excessive installation torque or variations in cavity/cartridge machining. This model boasts an impressive flow capacity of up to 80 gpm (320 L/min) and requires a minimum pilot pressure of 300 psi (20 bar) to shift the valve. For a full shift at rated flow, a pilot pressure of 350 psi (24 bar) is necessary. The maximum valve leakage at operational conditions is maintained at 3 in\u00b3/min at 1000 psi (50 cc/min at 70 bar), ensuring efficient operation. Installation specifications include a valve hex size of 1-5/8 inches (41.3 mm) and an installation torque range between 350 to 375 lbf\u00b7ft (474 to 508 Nm). The DDHGXYV weighs approximately 5.9 lbs (2.7 kg), making it robust yet manageable for various installations. This model uses Viton seals for enhanced performance under varying conditions, further emphasizing its suitability for complex hydraulic systems where reliability and precision are critical.
The Sun Hydraulics DDHGXYV (DDHGXYV) is a high-performance, two-position, 3-way directional cartridge valve. This model is versatile with its six ports, although port 5 is not utilized. It can be configured in up to five different spool configurations according to specific application needs. The supply port for this model is designated as port 3, and all ports are capable of handling a maximum operating pressure of 5000 psi (350 bar). The valve's performance and capacity vary depending on the spool type specified. Key features of the DDHGXYV include a hardened spool and sleeve that ensure low leakage rates and superior wear characteristics, essential for maintaining efficiency and longevity in demanding environments. Additionally, the valve incorporates Sun's floating style construction which minimizes internal part binding\u2014a common issue resulting from excessive installation torque or variations in cavity/cartridge machining. This model boasts an impressive flow capacity of up to 80 gpm (320 L/min) and requires a minimum pilot pressure of 300 psi (20 bar) to shift the valve. For a full shift at rated flow, a pilot pressure of 350 psi (24 bar) is necessary. The maximum valve leakage at operational conditions is maintained at 3 in\u00b3/min at 1000 psi (50 cc/min at 70 bar), ensuring efficient operation. Installation specifications include a valve hex size of 1-5/8 inches (41.3 mm) and an installation torque range between 350 to 375 lbf\u00b7ft (474 to 508 Nm). The DDHGXYV weighs approximately 5.9 lbs (2.7 kg), making it robust yet manageable for various installations. This model uses Viton seals for enhanced performance under varying conditions, further emphasizing its suitability for complex hydraulic systems where reliability and precision are critical.
Two-position, 3-way directional cartridges are 6-port (port 5 is not used) directional valves that can be configured with up to 5 different spool configurations. The supply port is port 3 and all ports will accept 5000 psi (350 bar). Capacity for these pilot-to-shift valves is dependent on the spool type specified.
- Leakage listed in technical data is for each path.
- Pressure at port 6 directly opposes port 1.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-54A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 300 psi20 bar |
| Pilot Pressure Required for Full Shift at Rated Flow | 350 psi24 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 3 in³/min.@1000 psi50 cc/min.@70 bar |
| Pilot Volume Displacement | .27 in³4,4 cc |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Model Weight | 5.9 lb2,7 kg |
| Seal kit - Cartridge | Viton: 990-054-006 |
