SUN HYDRAULICS
DKFPCAN
$184.96 USD
- SUN HYDRAULICS
- Material:DKFPCAN
- Model:DKFP-CAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DKFPCAN (DKFPCAN) is a high-performance hydraulic valve designed for efficient fluid control in various applications. This model, part of the T22A cavity series 2, features a normally closed, balanced poppet switching element that operates under a maximum pressure of 5000 psi or 350 bar. The valve is structured to shift from closed to open when the pilot pressure at port 3 surpasses the internally set threshold, thanks to its integral pilot relief stage. The DKFPCAN is engineered to provide reliable and predictable switching performance with minimal leakage\u2014typically less than 10 drops per minute at maximum operating pressure. It supports a flow capacity of up to 30 gpm or 120 L/min and requires a minimum pilot pressure of 300 psi or 20 bar to activate the valve shift. Each port in this valve can withstand pressures up to 5000 psi or 350 bar, ensuring robust operation across various conditions. In terms of construction, the DKFPCAN incorporates Sun\u2019s floating style design which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This feature enhances the overall durability and reliability of the valve in demanding operational environments. The low internal leakage rate and fully sealed ports make this model particularly suitable for applications where fluid control precision is critical. Additionally, any backpressure at the drain port directly adds to the valve setting, providing further operational control. Overall, Sun Hydraulics' DKFPCAN offers precise hydraulic control with robust construction and high-pressure capability, making it an essential component for systems requiring dependable fluid management under varying pressures and flow conditions.
The Sun Hydraulics DKFPCAN (DKFPCAN) is a high-performance hydraulic valve designed for efficient fluid control in various applications. This model, part of the T22A cavity series 2, features a normally closed, balanced poppet switching element that operates under a maximum pressure of 5000 psi or 350 bar. The valve is structured to shift from closed to open when the pilot pressure at port 3 surpasses the internally set threshold, thanks to its integral pilot relief stage. The DKFPCAN is engineered to provide reliable and predictable switching performance with minimal leakage\u2014typically less than 10 drops per minute at maximum operating pressure. It supports a flow capacity of up to 30 gpm or 120 L/min and requires a minimum pilot pressure of 300 psi or 20 bar to activate the valve shift. Each port in this valve can withstand pressures up to 5000 psi or 350 bar, ensuring robust operation across various conditions. In terms of construction, the DKFPCAN incorporates Sun\u2019s floating style design which minimizes potential internal binding caused by excessive installation torque or variations in cavity/cartridge machining. This feature enhances the overall durability and reliability of the valve in demanding operational environments. The low internal leakage rate and fully sealed ports make this model particularly suitable for applications where fluid control precision is critical. Additionally, any backpressure at the drain port directly adds to the valve setting, providing further operational control. Overall, Sun Hydraulics' DKFPCAN offers precise hydraulic control with robust construction and high-pressure capability, making it an essential component for systems requiring dependable fluid management under varying pressures and flow conditions.
This is a normally closed, balanced poppet, switching element. When pilot pressure is applied to port 3, the poppet remains closed until the pilot pressure reaches the setting established by the integral pilot relief stage, at which point the poppet shifts to the open position.
- Unique balanced construction provides predictable switching with 5000 psi (350 bar) at both port 1 and port 2. When the remote pressure signal at port 3 exceeds the internal valve setting, the valve shifts to the open position.
- Any backpressure at the drain port is directly additive to the valve setting.
- Valve will reseat when the pilot pressure falls to 85% of the cracking value.
- Port 1 and port 2 are fully sealed from port 3 and port 4. Ports 3 and 4 are positively sealed.
- Leakage rate between port 1 and port 2 is very low, typically less than 10 drops/min. at 5000 psi (0,7 cc/min at 350 bar).
- All ports will accept 5000 psi (350 bar).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-22A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 300 psi20 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Control Pilot Flow | See Performance DataSee Performance Data |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 drops/min.@5000 psi0,7 cc/min.@350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Seal kit - Cartridge | Viton: 990-022-006 |
