SUN HYDRAULICS
DMDMTRN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DMDMTRN (DMDMTRN) is a manually operated, 2-position, 3-way directional cartridge valve designed primarily for intermittent use as a manual override within hydraulic circuits. Featuring Sun's TwistLock manual override mechanism, the DMDMTRN valve offers reliable control over the flow direction with a mechanical life expectancy of approximately 7,000 cycles. This direct-acting, balanced spool valve is engineered to provide precise operation through its various control options. The momentary-twist control (option T) allows for temporary shifting of the valve by twisting the knob clockwise; upon release, the valve automatically returns to its default position. For more sustained shift positions without load holding, the detent-lock control (option L) enables the operator to lock the valve in a chosen position by twisting the knob counterclockwise until further adjustment. The dual-operation control (option D) combines both functionalities, offering flexibility depending on operational needs. Constructed with Sun's floating style design, the DMDMTRN minimizes internal part binding and ensures consistent performance even under variable installation torques or cavity/cartridge machining discrepancies. It supports up to 12 gpm/45 L/min flow capacity and can withstand maximum operating pressures up to 5000 psi/350 bar. The operational integrity of this valve is maintained with minimal leakage and an operating torque requirement of about 10 lbf in./1.2 Nm. With a hex size of 7/8 in./22.2 mm and recommended installation torque between 30 \u2013 35 lbf ft/41 \u2013 47 Nm, this robust component is suited for manual operations where precise hydraulic flow direction control is essential but not frequently adjusted. It uses Viton seals (990411006) ensuring durability and resistance against various operational environments.
