SUN HYDRAULICS
DNDATJV214

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DNDATJV214 (DNDATJV214) is a solenoid-operated, 4-way, 2-position cartridge valve known for its direct-acting, balanced spool directional capabilities. The valve is fatigue-rated for 5000 psi (350 bar) service, ensuring durability and reliability in high-pressure applications. It does not require a minimum hydraulic pressure for operation, making it versatile across various systems. This model offers several manual override options; however, note that manual overrides are incompatible with weatherized coils. The detent mechanism in the manual override is designed for temporary actuation and has a mechanical life expectancy of about 7,000 cycles. The valve incorporates EPDM seals suited for phosphate ester fluid systems but should not be exposed to petroleum-based fluids as they can cause seal damage. Its wet armature design allows the working fluid to surround the armature, which can influence performance if the coil remains energized over long periods due to potential heat exposure. A wide range of coil termination and voltage options are available, providing flexibility in installation and operation. With a high-efficiency solenoid design, this valve delivers significant spool actuating force per watt expended, ensuring reliable shifting. Coils are interchangeable with other Sun Series 1 solenoid products and can be mounted bidirectionally on the tube. Coil connector options offer protection ratings up to IP69K for robust environmental resistance. Additional features include Sun's floating style construction to minimize internal binding risks due to installation torque or machining variations. The DNDATJV214 fits within cavity T-31A and operates at a capacity of 10 gpm (40 L/min). It boasts a response time of approximately 50 milliseconds and handles maximum leakage of 10 in\u00b3/min at 3000 psi (160 cc/min at 210 bar). This model supports a switching frequency of up to 15,000 cycles per hour and requires specific torque settings during installation to ensure optimal performance.
