SUN HYDRAULICS
DNDYXXV712
$273.91 USD
- SUN HYDRAULICS
- Material:DNDYXXV712
- Model:DNDY-XXV@712
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DNDYXXV712 (DNDYXXV712) is a solenoid-operated 6-way, 2-position cartridge valve designed for selecting between two separate circuits. In its de-energized state, it connects ports P and T to the first circuit, and when energized, it switches to connect P and T to the second circuit. This direct-acting, balanced spool valve is engineered without the need for minimum hydraulic pressure for operation. The solenoid tube assembly is fatigue-rated for service pressures up to 5000 psi (350 bar), ensuring durability in demanding applications. It features a wet armature design where the working fluid surrounds the armature, which can impact performance if the coil is energized for extended periods. The valve's manual control options include configurations with or without manual overrides; however, these are not compatible with weatherized coils. The DNDYXXV712 incorporates Sun's floating style construction to prevent internal binding from excessive installation torque or machining variations. It offers a capacity of 5 gpm (20 L/min) and has a typical response time of 50 ms. With a maximum leakage rate of 5 in\u00b3/min at 3000 psi (80 cc/min at 210 bar), this cartridge valve supports high switching frequencies up to 15,000 cycles per hour. Coils are interchangeable with other Sun Series 1 solenoid products and offer various termination and voltage options with surge protection capabilities. The valve has a mechanical life expectancy of approximately 7,000 cycles in models equipped with D or L control detent mechanisms. Additional weatherized coils are available for enhanced environmental protection, making this valve suitable for varied applications requiring reliable circuit selection under high-pressure conditions.
The Sun Hydraulics DNDYXXV712 (DNDYXXV712) is a solenoid-operated 6-way, 2-position cartridge valve designed for selecting between two separate circuits. In its de-energized state, it connects ports P and T to the first circuit, and when energized, it switches to connect P and T to the second circuit. This direct-acting, balanced spool valve is engineered without the need for minimum hydraulic pressure for operation. The solenoid tube assembly is fatigue-rated for service pressures up to 5000 psi (350 bar), ensuring durability in demanding applications. It features a wet armature design where the working fluid surrounds the armature, which can impact performance if the coil is energized for extended periods. The valve's manual control options include configurations with or without manual overrides; however, these are not compatible with weatherized coils. The DNDYXXV712 incorporates Sun's floating style construction to prevent internal binding from excessive installation torque or machining variations. It offers a capacity of 5 gpm (20 L/min) and has a typical response time of 50 ms. With a maximum leakage rate of 5 in\u00b3/min at 3000 psi (80 cc/min at 210 bar), this cartridge valve supports high switching frequencies up to 15,000 cycles per hour. Coils are interchangeable with other Sun Series 1 solenoid products and offer various termination and voltage options with surge protection capabilities. The valve has a mechanical life expectancy of approximately 7,000 cycles in models equipped with D or L control detent mechanisms. Additional weatherized coils are available for enhanced environmental protection, making this valve suitable for varied applications requiring reliable circuit selection under high-pressure conditions.
This solenoid-operated 6-way, 2-position cartridge is a direct-acting, balanced spool valve. The typical use for this valve is to select between two separate circuits. The de-energized condition connects P and T to the first circuit and when energized connects P and T to the second circuit.
- The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service.
- This valve is direct actuated and requires no minimum hydraulic pressure for operation.
- On models equipped with the D or L control, the detent mechanism in the manual override is meant for temporary actuation. The D, L and T manual control assembly has a mechanical life expectancy of approximately 7,000 cycles.
- This cartridge has several manual override choices, including no manual override. See the CONFIGURATION section. Please note: Manual override functionality is not compatible with weatherized coils.
- This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.
- A wide variety of coil termination and voltage options are available, with and without surge protection. See the CONFIGURATION section.
- The solenoid's unique magnetic design results in a high efficiency solenoid, yielding high spool actuating force per Watt expended, leading to reliable valve shifting.
- Coils are interchangeable with other Sun Series 1 solenoid products and can be mounted on the tube in either direction.
- Coil connector options offer ratings up to IP69K. See individual coil product pages for details. Additional weatherized coils and kits are available for more complete environmental protection.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-61A |
| Series | 1 |
| Capacity | 5 gpm20 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Response Time - Typical | 50 ms50 ms |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 5 in³/min.@3000 psi80 cc/min.@210 bar |
| Switching Frequency | 15000 cycles/hr15000 cycles/hr |
| Manual Override Force Requirement | 5 lbs/1000 psi @ Port 133 N/100 bar @ Port 1 |
| Manual Override Stroke | .10 in.2,5 mm |
| Solenoid Tube Diameter | .75 in.19 mm |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .60 lb0,30 kg |
| Seal kit - Cartridge | Viton: 990-461-006 |
| Seal and nut kit - Coil | Viton: 990-770-006Viton: 990-770-006 |
