SUN HYDRAULICS
DODPKAN
$145.45 USD
- SUN HYDRAULICS
- Material:DODPKAN
- Model:DODP-KAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DODPKAN (DODPKAN) is a normally open, balanced poppet switching element designed for precise hydraulic control applications. This component features a unique balanced construction that allows for predictable switching at pressures up to 5000 psi (350 bar) at both port 1 and port 2. When pilot pressure is applied to port 3, the poppet remains open until the pressure reaches the setting established by the integral pilot relief stage, subsequently shifting to a closed position. The valve is hydraulically balanced between ports 1 and 2, ensuring low leakage rates of less than 10 drops/min at maximum operating pressure. The DODPKAN incorporates Sun's floating style construction, minimizing internal part binding due to excessive installation torque or machining variations. It requires a minimum pilot pressure of 400 psi (28 bar) to shift and can handle a capacity of up to 15 gpm (60 L/min). All ports are capable of accepting pressures up to 5000 psi (350 bar), with ports being fully sealed from each other to maintain system integrity. This valve is suitable for applications requiring reliable switching performance under high-pressure conditions while maintaining low leakage and operational stability.
The Sun Hydraulics DODPKAN (DODPKAN) is a normally open, balanced poppet switching element designed for precise hydraulic control applications. This component features a unique balanced construction that allows for predictable switching at pressures up to 5000 psi (350 bar) at both port 1 and port 2. When pilot pressure is applied to port 3, the poppet remains open until the pressure reaches the setting established by the integral pilot relief stage, subsequently shifting to a closed position. The valve is hydraulically balanced between ports 1 and 2, ensuring low leakage rates of less than 10 drops/min at maximum operating pressure. The DODPKAN incorporates Sun's floating style construction, minimizing internal part binding due to excessive installation torque or machining variations. It requires a minimum pilot pressure of 400 psi (28 bar) to shift and can handle a capacity of up to 15 gpm (60 L/min). All ports are capable of accepting pressures up to 5000 psi (350 bar), with ports being fully sealed from each other to maintain system integrity. This valve is suitable for applications requiring reliable switching performance under high-pressure conditions while maintaining low leakage and operational stability.
This is a normally open, balanced poppet, switching element. When pilot pressure is applied to port 3, the poppet remains open until the pilot pressure reaches the setting established by the integral pilot relief stage, at which point the poppet shifts to the closed position.
- Unique balanced construction provides predictable switching with 5000 psi (350 bar) at both port 1 and port 2. When the remote pressure signal at port 3 exceeds the internal valve setting, the valve shifts to the closed position.
- Any backpressure at the drain port is directly additive to the valve setting.
- Valve will open when the pilot pressure falls below 145 psi (10 bar).
- These valves are hydraulically balanced between port 1 and port 2.
- Port 1 and port 2 are fully sealed from port 3 and port 4. Ports 3 and 4 are positively sealed.
- Leakage rate between port 1 and port 2 is very low, typically less than 10 drops/min. at 5000 psi (0,7 cc/min at 350 bar).
- All ports will accept 5000 psi (350 bar).
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-21A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Minimum Pilot Pressure Required to Shift Valve | 400 psi28 bar |
| Maximum Operating Pressure | 5000 psi350 bar |
| Control Pilot Flow | See Performance DataSee Performance Data |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 10 drops/min.@5000 psi0,7 cc/min.@350 bar |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Seal kit - Cartridge | Viton: 990-021-006 |
