SUN HYDRAULICS
DPBBKKV
$120.83 USD
- SUN HYDRAULICS
- Material:DPBBKKV
- Model:DPBB-KKV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DPBBKKV (DPBBKKV) is a normally closed, pilot-operated, 2-way directional cartridge valve designed for moderate flow circuits. It can function independently or be used to actuate larger pilot-operated directional or logic cartridges. The valve operates by shifting when the pressure differential between port 1 and port 3 surpasses its set threshold, with pressure at port 3 directly adding to the valve's setting. This makes port 3 potentially unsuitable as a work port in certain circuits, suggesting the use of a 4-port version if necessary. The DPBBKKV is not bistable and can modulate between two positions based on pilot pressure exceeding the valve setting. It features Sun's floating style construction to minimize internal binding risks due to installation torque or machining variations. The valve fits into cavity T-11A and belongs to Series 1 with a capacity of 7 gpm (28 L/min). It is factory set at pressures established at 4 gpm (15 L/min) and supports a maximum operating pressure of 5000 psi (350 bar). Control pilot flow ranges from 7 to 10 in\u00b3/min (0.11 to 0.16 L/min), while maximum leakage at 110 SUS (24 cSt) is limited to 1 in\u00b3/min at 1000 psi (15 cc/min at 70 bar). The adjustment requires up to five clockwise turns for increased settings, with specific hex sizes for the valve, adjustment screw, and locknut ensuring precise installation torque specifications are met. Weighing .60 lb (.30 kg), it comes equipped with a Viton seal kit for reliable performance across various applications requiring robust hydraulic control solutions.
The Sun Hydraulics DPBBKKV (DPBBKKV) is a normally closed, pilot-operated, 2-way directional cartridge valve designed for moderate flow circuits. It can function independently or be used to actuate larger pilot-operated directional or logic cartridges. The valve operates by shifting when the pressure differential between port 1 and port 3 surpasses its set threshold, with pressure at port 3 directly adding to the valve's setting. This makes port 3 potentially unsuitable as a work port in certain circuits, suggesting the use of a 4-port version if necessary. The DPBBKKV is not bistable and can modulate between two positions based on pilot pressure exceeding the valve setting. It features Sun's floating style construction to minimize internal binding risks due to installation torque or machining variations. The valve fits into cavity T-11A and belongs to Series 1 with a capacity of 7 gpm (28 L/min). It is factory set at pressures established at 4 gpm (15 L/min) and supports a maximum operating pressure of 5000 psi (350 bar). Control pilot flow ranges from 7 to 10 in\u00b3/min (0.11 to 0.16 L/min), while maximum leakage at 110 SUS (24 cSt) is limited to 1 in\u00b3/min at 1000 psi (15 cc/min at 70 bar). The adjustment requires up to five clockwise turns for increased settings, with specific hex sizes for the valve, adjustment screw, and locknut ensuring precise installation torque specifications are met. Weighing .60 lb (.30 kg), it comes equipped with a Viton seal kit for reliable performance across various applications requiring robust hydraulic control solutions.
Normally closed, pilot-operated, 2-way directional cartridges are switching devices typically used in moderate flow circuits. They can be used by themselves or to actuate larger pilot-operated directional cartridges or logic cartridges. The valve shifts when the pressure differential between port 1 and port 3 exceeds the setting.
- Pressure at port 3 is directly additive to the setting of the valve. Because of this, port 3 may not be useable as a work port in your circuit. If this is a consideration, the 4 port version of this valve may be a solution.
- Direct-acting and pilot-operated versions of these valves are interchangeable. They fit the same cavities and have the same flow paths.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- When pilot pressure exceeds the valve setting, pilot flow may be a consideration. See performance curves for pilot consumption vs. load pressure above the valve setting. If this is a problem, the direct acting version of this valve would be a solution.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 7 gpm28 L/min. |
| Factory Pressure Settings Established at | 4 gpm15 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Control Pilot Flow | 7 - 10 in³/min.0,11 - 0,16 L/min. |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 in³/min.@1000 psi15 cc/min.@70 bar |
| Adjustment - Number of Clockwise Turns to Increase Setting | 55 |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .60 lb0,30 kg |
| Seal kit - Cartridge | Viton: 990-011-006 |
