SUN HYDRAULICS
DRBCCAN
$128.77 USD
- SUN HYDRAULICS
- Material:DRBCCAN
- Model:DRBC-CAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DRBCCAN (Material Number: DRBCCAN) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. This valve serves as a switching device, with one port blocked and ports 2 to 3 open, making it suitable for standalone use or for actuating larger pilot-operated or logic cartridges. The valve shifts when the pressure differential between port 1 and port 3 surpasses the preset threshold, with pressure at port 3 directly adding to this setting. Notably, due to this feature, port 3 might not be suitable as a work port in certain circuit designs; in such cases, a four-port version may be more appropriate. The DRBCCAN boasts low internal leakage and minimal pilot flow consumption due to its direct-acting design. It offers interchangeability with pilot-operated versions, sharing the same cavities and flow paths. Additionally, this valve is capable of modulating between two positions rather than being bistable. The incorporation of Sun\u2019s floating style construction minimizes the risk of internal parts binding from excessive installation torque or machining variations. Key specifications include a T-11A cavity type, Series 1 classification, and a capacity of 7 gpm (28 L/min). The valve operates at pressures up to 5000 psi (350 bar) with maximum leakage of 2 in/min (30 cc/min) at 110 SUS (24 cSt). Factory pressure settings are established at a flow rate of 4 gpm (15 L/min). Installation requires a torque range of 30 - 35 lbf ft (41 - 47 Nm), while adjustments are made via an internal hex screw requiring up to five clockwise turns to increase settings. The model weighs .60 lb (.30 kg) and uses Viton seal kits for maintenance.
The Sun Hydraulics DRBCCAN (Material Number: DRBCCAN) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. This valve serves as a switching device, with one port blocked and ports 2 to 3 open, making it suitable for standalone use or for actuating larger pilot-operated or logic cartridges. The valve shifts when the pressure differential between port 1 and port 3 surpasses the preset threshold, with pressure at port 3 directly adding to this setting. Notably, due to this feature, port 3 might not be suitable as a work port in certain circuit designs; in such cases, a four-port version may be more appropriate. The DRBCCAN boasts low internal leakage and minimal pilot flow consumption due to its direct-acting design. It offers interchangeability with pilot-operated versions, sharing the same cavities and flow paths. Additionally, this valve is capable of modulating between two positions rather than being bistable. The incorporation of Sun\u2019s floating style construction minimizes the risk of internal parts binding from excessive installation torque or machining variations. Key specifications include a T-11A cavity type, Series 1 classification, and a capacity of 7 gpm (28 L/min). The valve operates at pressures up to 5000 psi (350 bar) with maximum leakage of 2 in/min (30 cc/min) at 110 SUS (24 cSt). Factory pressure settings are established at a flow rate of 4 gpm (15 L/min). Installation requires a torque range of 30 - 35 lbf ft (41 - 47 Nm), while adjustments are made via an internal hex screw requiring up to five clockwise turns to increase settings. The model weighs .60 lb (.30 kg) and uses Viton seal kits for maintenance.
Direct-acting, 3-way directional cartridges (1 blocked, 2 to 3 open) are switching devices typically used in moderate flow circuits. They can be used by themselves or to actuate larger pilot-operated directional cartridges or logic cartridges. The valve shifts when the pressure differential between port 1 and port 3 exceeds the setting.
- Pressure at port 3 is directly additive to the setting of the valve. Because of this, port 3 may not be useable as a work port in your circuit. If this is a consideration, the 4 port version of this valve may be a solution.
- Because of their direct-acting design, these cartridges feature low internal leakage and low pilot flow consumption.
- Direct-acting and pilot-operated versions of these valves are interchangeable. They fit the same cavities and have the same flow paths.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 7 gpm28 L/min. |
| Factory Pressure Settings Established at | 4 gpm15 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.30 cc/min. |
| Adjustment - Number of Clockwise Turns to Increase Setting | 55 |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .60 lb0,30 kg |
| Seal kit - Cartridge | Viton: 990-011-006 |
