SUN HYDRAULICS
DRBDOEV
$153.09 USD
- SUN HYDRAULICS
- Material:DRBDOEV
- Model:DRBD-OEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DRBDOEV (DRBDOEV) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. This versatile component can function independently or be used to actuate larger pilot-operated directional cartridges or logic cartridges. The valve operates by shifting when the pressure differential between port 1 and port 3 surpasses the set threshold. It's important to note that pressure at port 3 contributes directly to the valve's setting, potentially limiting its use as a work port in certain circuits; in such cases, a 4-port version might be more suitable. Featuring low internal leakage and minimal pilot flow consumption due to its direct-acting design, this valve offers reliable performance. Both direct-acting and pilot-operated versions of these valves are interchangeable, sharing the same cavities and flow paths. The DRBDOEV is not bistable but can modulate between two positions, enhancing control capabilities within hydraulic systems. Constructed with Sun's floating style design, this cartridge minimizes internal part binding risks from excessive installation torque or cavity/cartridge machining variations. It fits into cavity T-11A and belongs to series 1 with a capacity of 7 gpm (28 L/min). The factory pressure settings are established at 4 gpm (15 L/min), with a maximum operating pressure of 5000 psi (350 bar). The valve's maximum leakage at 110 SUS (24 cSt) is rated at 2 in\u00b3/min (30 cc/min). Additional specifications include an adjustment range requiring up to five clockwise turns to increase setting, a hex size of 7/8 inch (22.2 mm), installation torque between 30\u201335 lbf ft (41\u201347 Nm), an internal hex size for adjustment screw of 5/32 inch (4 mm), and locknut torque ranging from 80\u201390 lbf in (9\u201310 Nm). Weighing .60 lb (.30 kg), the DRBDOEV includes a Viton seal kit for enhanced durability.
The Sun Hydraulics DRBDOEV (DRBDOEV) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. This versatile component can function independently or be used to actuate larger pilot-operated directional cartridges or logic cartridges. The valve operates by shifting when the pressure differential between port 1 and port 3 surpasses the set threshold. It's important to note that pressure at port 3 contributes directly to the valve's setting, potentially limiting its use as a work port in certain circuits; in such cases, a 4-port version might be more suitable. Featuring low internal leakage and minimal pilot flow consumption due to its direct-acting design, this valve offers reliable performance. Both direct-acting and pilot-operated versions of these valves are interchangeable, sharing the same cavities and flow paths. The DRBDOEV is not bistable but can modulate between two positions, enhancing control capabilities within hydraulic systems. Constructed with Sun's floating style design, this cartridge minimizes internal part binding risks from excessive installation torque or cavity/cartridge machining variations. It fits into cavity T-11A and belongs to series 1 with a capacity of 7 gpm (28 L/min). The factory pressure settings are established at 4 gpm (15 L/min), with a maximum operating pressure of 5000 psi (350 bar). The valve's maximum leakage at 110 SUS (24 cSt) is rated at 2 in\u00b3/min (30 cc/min). Additional specifications include an adjustment range requiring up to five clockwise turns to increase setting, a hex size of 7/8 inch (22.2 mm), installation torque between 30\u201335 lbf ft (41\u201347 Nm), an internal hex size for adjustment screw of 5/32 inch (4 mm), and locknut torque ranging from 80\u201390 lbf in (9\u201310 Nm). Weighing .60 lb (.30 kg), the DRBDOEV includes a Viton seal kit for enhanced durability.
Direct-acting, 3-way directional cartridges (1 to 2 open, 3 blocked) are switching devices typically used in moderate flow circuits. They can be used by themselves or to actuate larger pilot-operated directional cartridges or logic cartridges. The valve shifts when the pressure differential between port 1 and port 3 exceeds the setting.
- Pressure at port 3 is directly additive to the setting of the valve. Because of this, port 3 may not be useable as a work port in your circuit. If this is a consideration, the 4 port version of this valve may be a solution.
- Because of their direct-acting design, these cartridges feature low internal leakage and low pilot flow consumption.
- Direct-acting and pilot-operated versions of these valves are interchangeable. They fit the same cavities and have the same flow paths.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-11A |
| Series | 1 |
| Capacity | 7 gpm28 L/min. |
| Factory Pressure Settings Established at | 4 gpm15 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.30 cc/min. |
| Adjustment - Number of Clockwise Turns to Increase Setting | 55 |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .60 lb0,30 kg |
| Seal kit - Cartridge | Viton: 990-011-006 |
