SUN HYDRAULICS
DRBOCAN
$143.76 USD
- SUN HYDRAULICS
- Material:DRBOCAN
- Model:DRBO-CAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DRBOCAN (Material Number: DRBOCAN) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. This versatile component can function independently or actuate larger pilot-operated directional or logic cartridges. The valve transitions when the pressure differential between port 1 and port 4 surpasses the set threshold, with port 3 serving as a work port. The bidirectional flow paths between ports 2 and 3, and ports 1 and 2, enhance operational flexibility. Thanks to its direct-acting design, the DRBOCAN features low internal leakage and minimal pilot flow consumption. It is interchangeable with pilot-operated versions, sharing identical cavities and flow paths. The DRBOCAN incorporates Sun's floating style construction to reduce the risk of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. This non-bistable valve can modulate between its two positions and supports a maximum operating pressure of 5000 psi (350 bar). While it has a capacity of 7 gpm (28 L/min), factory pressure settings are established at 4 gpm (15 L/min). The maximum recommended pressure at port 3 is limited to 3000 psi (210 bar) due to fatigue strength limits. Installation specifications include a valve hex size of 7/8 in. (22.2 mm), an adjustment screw internal hex size of 5/32 in. (4 mm), and a locknut hex size of 9/16 in. (15 mm). The installation torque ranges from 30 to 35 lbf ft (41 to 47 Nm), while the locknut torque ranges from 80 to 90 lbf in. (9 to10 Nm). The model weighs approximately .55 lb (.25 kg) and utilizes Viton seal kits for optimal performance under various conditions.
The Sun Hydraulics DRBOCAN (Material Number: DRBOCAN) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. This versatile component can function independently or actuate larger pilot-operated directional or logic cartridges. The valve transitions when the pressure differential between port 1 and port 4 surpasses the set threshold, with port 3 serving as a work port. The bidirectional flow paths between ports 2 and 3, and ports 1 and 2, enhance operational flexibility. Thanks to its direct-acting design, the DRBOCAN features low internal leakage and minimal pilot flow consumption. It is interchangeable with pilot-operated versions, sharing identical cavities and flow paths. The DRBOCAN incorporates Sun's floating style construction to reduce the risk of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. This non-bistable valve can modulate between its two positions and supports a maximum operating pressure of 5000 psi (350 bar). While it has a capacity of 7 gpm (28 L/min), factory pressure settings are established at 4 gpm (15 L/min). The maximum recommended pressure at port 3 is limited to 3000 psi (210 bar) due to fatigue strength limits. Installation specifications include a valve hex size of 7/8 in. (22.2 mm), an adjustment screw internal hex size of 5/32 in. (4 mm), and a locknut hex size of 9/16 in. (15 mm). The installation torque ranges from 30 to 35 lbf ft (41 to 47 Nm), while the locknut torque ranges from 80 to 90 lbf in. (9 to10 Nm). The model weighs approximately .55 lb (.25 kg) and utilizes Viton seal kits for optimal performance under various conditions.
Direct-acting, 3-way directional cartridges (1 blocked, 2 to 3 open) are switching devices typically used in moderate flow circuits. They can be used by themselves or to actuate larger pilot-operated directional cartridges or logic cartridges. The valve shifts when the pressure differential between port 1 and port 4 exceeds the setting.
- Port 3 can be used as a work port.
- The flow path between port 2 and port 3 is bidirectional.
- Because of their direct-acting design, these cartridges feature low internal leakage and low pilot flow consumption.
- Direct-acting and pilot-operated versions of these valves are interchangeable. They fit the same cavities and have the same flow paths.
- Pressure at port 4 is directly additive to the setting of the valve.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- The flow path between port 1 and port 2 is bidirectional.
- Maximum pressure at port 3 should be limited to 3000 psi (210 bar). This is due to fatigue strength limits not hydraulic operating limits.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-21A |
| Series | 1 |
| Capacity | 7 gpm28 L/min. |
| Factory Pressure Settings Established at | 4 gpm15 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.30 cc/min. |
| Adjustment - Number of Clockwise Turns to Increase Setting | 55 |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .55 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-021-006 |
