SUN HYDRAULICS
DRCOCAN
$182.48 USD
- SUN HYDRAULICS
- Material:DRCOCAN
- Model:DRCO-CAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DRCOCAN (Material Number: DRCOCAN) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. It is versatile in application, functioning independently or as an actuator for larger pilot-operated directional or logic cartridges. The valve operates by shifting when the pressure differential between port 1 and port 4 surpasses the preset level. Notably, port 3 can be utilized as a work port. Thanks to its direct-acting design, the DRCOCAN ensures low internal leakage and minimal pilot flow consumption. This model is interchangeable with pilot-operated versions, fitting identical cavities and maintaining consistent flow paths. The valve features Sun's floating style construction, reducing the risk of internal component binding due to excessive installation torque or machining variations. It is capable of modulating between two positions rather than being bistable. The maximum pressure at port 3 should not exceed 3000 psi (210 bar) due to fatigue strength limitations rather than hydraulic operational limits. With a cavity size of T-22A and a series designation of 2, this cartridge has a capacity of up to 15 gpm (60 L/min) and factory pressure settings established at 4 gpm (15 L/min). It can withstand maximum operating pressures of up to 5000 psi (350 bar). Additional specifications include a maximum valve leakage rate at 110 SUS (24 cSt) of 2 in\u00b3/min (30 cc/min), with an adjustment range requiring up to five clockwise turns to increase settings. The valve hex size measures at 1-1/8 inches (28.6 mm), with an installation torque specification of 45-50 lbf ft (61-68 Nm). For adjustments, the internal hex size is set at 5/32 inches (4 mm), while the locknut hex size is set at 9/16 inches (15 mm) with a locknut torque range of 80-90 lbf in (9-10 Nm). The model weighs approximately .55 lb (.25 kg) and comes with a Viton seal kit under part number: 990022006.
The Sun Hydraulics DRCOCAN (Material Number: DRCOCAN) is a direct-acting, 3-way directional cartridge valve designed for moderate flow circuits. It is versatile in application, functioning independently or as an actuator for larger pilot-operated directional or logic cartridges. The valve operates by shifting when the pressure differential between port 1 and port 4 surpasses the preset level. Notably, port 3 can be utilized as a work port. Thanks to its direct-acting design, the DRCOCAN ensures low internal leakage and minimal pilot flow consumption. This model is interchangeable with pilot-operated versions, fitting identical cavities and maintaining consistent flow paths. The valve features Sun's floating style construction, reducing the risk of internal component binding due to excessive installation torque or machining variations. It is capable of modulating between two positions rather than being bistable. The maximum pressure at port 3 should not exceed 3000 psi (210 bar) due to fatigue strength limitations rather than hydraulic operational limits. With a cavity size of T-22A and a series designation of 2, this cartridge has a capacity of up to 15 gpm (60 L/min) and factory pressure settings established at 4 gpm (15 L/min). It can withstand maximum operating pressures of up to 5000 psi (350 bar). Additional specifications include a maximum valve leakage rate at 110 SUS (24 cSt) of 2 in\u00b3/min (30 cc/min), with an adjustment range requiring up to five clockwise turns to increase settings. The valve hex size measures at 1-1/8 inches (28.6 mm), with an installation torque specification of 45-50 lbf ft (61-68 Nm). For adjustments, the internal hex size is set at 5/32 inches (4 mm), while the locknut hex size is set at 9/16 inches (15 mm) with a locknut torque range of 80-90 lbf in (9-10 Nm). The model weighs approximately .55 lb (.25 kg) and comes with a Viton seal kit under part number: 990022006.
Direct-acting, 3-way directional cartridges (1 blocked, 2 to 3 open) are switching devices typically used in moderate flow circuits. They can be used by themselves or to actuate larger pilot-operated directional cartridges or logic cartridges. The valve shifts when the pressure differential between port 1 and port 4 exceeds the setting.
- Port 3 can be used as a work port.
- Because of their direct-acting design, these cartridges feature low internal leakage and low pilot flow consumption.
- Direct-acting and pilot-operated versions of these valves are interchangeable. They fit the same cavities and have the same flow paths.
- Pressure at port 4 is directly additive to the setting of the valve.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Maximum pressure at port 3 should be limited to 3000 psi (210 bar). This is due to fatigue strength limits not hydraulic operating limits.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-22A |
| Series | 2 |
| Capacity | 15 gpm60 L/min. |
| Factory Pressure Settings Established at | 4 gpm15 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.30 cc/min. |
| Adjustment - Number of Clockwise Turns to Increase Setting | 55 |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .55 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-022-006 |
