SUN HYDRAULICS
DSCOXCV
$141.48 USD
- SUN HYDRAULICS
- Material:DSCOXCV
- Model:DSCO-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSCOXCV (DSCOXCV) is a spring-offset, high-side shuttle cartridge valve designed for specific hydraulic applications requiring precise control of fluid direction. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When the pressure at port 2 surpasses that at port 4, the valve shifts to connect the common port to port 2, subsequently blocking port 4. Notably, although this valve is designed for a 4-port cavity, the nose port (port 1) remains unused. The DSCOXCV incorporates Sun's floating style construction, which minimizes internal binding risks due to excessive installation torque or machining discrepancies in cavity and cartridge. It fits into a T-31A cavity and belongs to Series 1 with a capacity of handling up to 15 gpm (60 L/min). The maximum operating pressure for this model is rated at an impressive 5000 psi (350 bar), ensuring robust performance under demanding conditions. Valve leakage is minimal, with a maximum of only 1 in\u00b3/min at 1000 psi (15 cc/min at 70 bar). The hex size for installation is measured at .78 inches (22.2 mm), and it should be installed with a torque between 30 - 35 lbf ft (41 - 47 Nm). Weighing just .40 lb (.20 kg), this lightweight component also comes with an optional Viton seal kit under part number: 990031006.
The Sun Hydraulics DSCOXCV (DSCOXCV) is a spring-offset, high-side shuttle cartridge valve designed for specific hydraulic applications requiring precise control of fluid direction. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When the pressure at port 2 surpasses that at port 4, the valve shifts to connect the common port to port 2, subsequently blocking port 4. Notably, although this valve is designed for a 4-port cavity, the nose port (port 1) remains unused. The DSCOXCV incorporates Sun's floating style construction, which minimizes internal binding risks due to excessive installation torque or machining discrepancies in cavity and cartridge. It fits into a T-31A cavity and belongs to Series 1 with a capacity of handling up to 15 gpm (60 L/min). The maximum operating pressure for this model is rated at an impressive 5000 psi (350 bar), ensuring robust performance under demanding conditions. Valve leakage is minimal, with a maximum of only 1 in\u00b3/min at 1000 psi (15 cc/min at 70 bar). The hex size for installation is measured at .78 inches (22.2 mm), and it should be installed with a torque between 30 - 35 lbf ft (41 - 47 Nm). Weighing just .40 lb (.20 kg), this lightweight component also comes with an optional Viton seal kit under part number: 990031006.
Spring-offset, high-side shuttle cartridges are 2-position valves that have a normal (offset) position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 rises above the pressure at port 4, the cartridge shifts to connect the common port to port 2 with port 4 then blocked.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-31A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 1 in³/min.@1000 psi15 cc/min.@70 bar |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-031-006 |
