SUN HYDRAULICS
DSCOXEV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSCOXEV (DSCOXEV) is a spring-offset, high-side shuttle cartridge valve designed for 2-position operation within hydraulic systems. This valve features a normal offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When the pressure at port 2 exceeds that at port 4, the cartridge shifts, connecting the common port to port 2 and blocking port 4. Although designed for a 4-port cavity, the nose port (port 1) remains unused. This model incorporates Sun's floating style construction, which reduces the risk of internal parts binding due to excessive installation torque or variations in cavity/cartridge machining. The DSCOXEV is built for use in T-31A cavities and belongs to Series 1 with a capacity of up to 15 gpm (60 L/min). It can operate under a maximum pressure of 5000 psi (350 bar). The valve exhibits minimal leakage at maximum conditions, with leakage rates capped at 1 in\u00b3/min (15 cc/min) at pressures of up to 1000 psi (70 bar). The valve hex size measures .78 inches (22.2 mm), and it requires an installation torque between 30 and 35 lbf-ft (41 to 47 Nm). Its compact design weighs approximately .40 lb (.20 kg). For maintenance or replacement, a Viton seal kit is available under part number 990031006. The DSCOXEV is well-suited for applications requiring reliable shuttle operations with minimal risk of binding or leakage, ensuring stable performance in demanding hydraulic systems.
