SUN HYDRAULICS
DSCSXGV
$128.97 USD
- SUN HYDRAULICS
- Material:DSCSXGV
- Model:DSCS-XGV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSCSXGV (DSCSXGV) is a highside shuttle cartridge valve primarily utilized in full-time regeneration circuits. This valve is designed to manage overrunning load control in regeneration applications, especially where the load tends to extend the cylinder. It features a unique ability to connect the higher pressure work port, either port 2 or 4, to the common port 3 when both work ports are at equal pressures, allowing it to spring-center to an all-ports-blocked position. Notably, this model does not prevent drift due to spool leakage. The hardened spool-sleeve construction ensures excellent wear characteristics and minimizes cross leakage, enhancing durability and reliability. Despite being designed for a 4-port cavity, the nose port 1 remains unused. This valve incorporates Sun's floating style construction, which reduces the likelihood of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. With a capacity of 15 gpm (60 L/min) and a maximum operating pressure of 5000 psi (350 bar), it offers robust performance for demanding applications. The maximum valve leakage at 110 SUS (24 cSt) is rated at 2 in/min (1000 psi) or 30 cc/min (70 bar). The DSCSXGV model has a hex size of 7/8 inches (22.2 mm) and should be installed with a torque between 30 - 35 lbf ft (41 - 47 Nm). Weighing approximately .40 lb (.20 kg), it is lightweight yet effective for its intended purpose. For maintenance or replacements, a Viton seal kit is available under part number 990031006.
The Sun Hydraulics DSCSXGV (DSCSXGV) is a highside shuttle cartridge valve primarily utilized in full-time regeneration circuits. This valve is designed to manage overrunning load control in regeneration applications, especially where the load tends to extend the cylinder. It features a unique ability to connect the higher pressure work port, either port 2 or 4, to the common port 3 when both work ports are at equal pressures, allowing it to spring-center to an all-ports-blocked position. Notably, this model does not prevent drift due to spool leakage. The hardened spool-sleeve construction ensures excellent wear characteristics and minimizes cross leakage, enhancing durability and reliability. Despite being designed for a 4-port cavity, the nose port 1 remains unused. This valve incorporates Sun's floating style construction, which reduces the likelihood of internal parts binding due to excessive installation torque or cavity/cartridge machining variations. With a capacity of 15 gpm (60 L/min) and a maximum operating pressure of 5000 psi (350 bar), it offers robust performance for demanding applications. The maximum valve leakage at 110 SUS (24 cSt) is rated at 2 in/min (1000 psi) or 30 cc/min (70 bar). The DSCSXGV model has a hex size of 7/8 inches (22.2 mm) and should be installed with a torque between 30 - 35 lbf ft (41 - 47 Nm). Weighing approximately .40 lb (.20 kg), it is lightweight yet effective for its intended purpose. For maintenance or replacements, a Viton seal kit is available under part number 990031006.
High-side shuttle cartridges are most often used in full-time regeneration circuits. When both work ports (ports 2 and 4) are at equal pressures the valve is spring-centered to an all-ports-blocked position. When one of the work ports (port 2 or 4) sees a higher pressure it is connected to the common port (port 3).
- This valve provides overrunning load control in regeneration applications where the load tends to extend the cylinder. Because there is spool leakage, it does not prevent drift.
- Hardened spool/sleeve construction provides excellent wear characteristics and minimizes cross leakage.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-31A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) | 2 in³/min.@1000 psi30 cc/min.@70 bar |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-031-006 |
