SUN HYDRAULICS
DSCYXCV
$129.17 USD
- SUN HYDRAULICS
- Material:DSCYXCV
- Model:DSCY-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSCYXCV (DSCYXCV) is a versatile vent-to-shift diverter valve designed as a 2-position, 3-way cartridge that is normally open from port 3 to port 4. When port 1 is vented and the pressure differential between port 3 and port 1 surpasses the spring force, the valve shifts to connect port 3 to port 2. This model is not bistable, allowing it to modulate between its two positions. The vent flow out of port 1 is pressure compensated. For operation, a pressure source must be present at port 3 relative to port 1. A practical application for this valve includes using it in pairs for selecting between two motors or pumps. Additionally, one pilot valve can vent multiple diverter valves if blocking checks are implemented at each diverter's port 1; otherwise, interaction may occur between high and low-pressure sections of the circuit. The DSCYXCV features a self-cleaning vent-to-shift function that resists contamination effectively. Its hardened spool and sleeve ensure low spool leakage rates and superior wear characteristics over time. The valve incorporates Sun's floating style construction, reducing the risk of internal parts binding due to excessive installation torque or machining variations in cavity/cartridge setups. It fits into a T-31A cavity and belongs to Series 1 with a capacity of up to 15 gpm (60 L/min). The maximum operating pressure is rated at 5000 psi (350 bar), with a nominal vent flow of approximately .38 L/min (23 in\u00b3/min). The valve has a hex size of .78 inches (22.2 mm) and should be installed with a torque ranging from 30 to 35 lbf ft (41 to 47 Nm). The model weighs .35 lb (.15 kg) and uses Viton seal kit number 990031006 for maintenance purposes.
The Sun Hydraulics DSCYXCV (DSCYXCV) is a versatile vent-to-shift diverter valve designed as a 2-position, 3-way cartridge that is normally open from port 3 to port 4. When port 1 is vented and the pressure differential between port 3 and port 1 surpasses the spring force, the valve shifts to connect port 3 to port 2. This model is not bistable, allowing it to modulate between its two positions. The vent flow out of port 1 is pressure compensated. For operation, a pressure source must be present at port 3 relative to port 1. A practical application for this valve includes using it in pairs for selecting between two motors or pumps. Additionally, one pilot valve can vent multiple diverter valves if blocking checks are implemented at each diverter's port 1; otherwise, interaction may occur between high and low-pressure sections of the circuit. The DSCYXCV features a self-cleaning vent-to-shift function that resists contamination effectively. Its hardened spool and sleeve ensure low spool leakage rates and superior wear characteristics over time. The valve incorporates Sun's floating style construction, reducing the risk of internal parts binding due to excessive installation torque or machining variations in cavity/cartridge setups. It fits into a T-31A cavity and belongs to Series 1 with a capacity of up to 15 gpm (60 L/min). The maximum operating pressure is rated at 5000 psi (350 bar), with a nominal vent flow of approximately .38 L/min (23 in\u00b3/min). The valve has a hex size of .78 inches (22.2 mm) and should be installed with a torque ranging from 30 to 35 lbf ft (41 to 47 Nm). The model weighs .35 lb (.15 kg) and uses Viton seal kit number 990031006 for maintenance purposes.
This vent-to-shift diverter valve is a 2-position, 3-way cartridge that is normally open from port 3 to port 4. When port 1 is vented, the pressure differential between port 3 and port 1 exceeds the spring force causing the valve to shift, thereby connecting port 3 to port 2.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Vent flow out of port 1 is pressure compensated and is listed in Technical Data.
- There must be a pressure source at port 3, relative to port 1, to shift the valve.
- One application of this valve is to be used in pairs to select between 2 motors or pumps.
- One pilot valve may be used to vent multiple diverter valves if blocking checks are used at port 1 of each diverter. If blocking checks are not used there will be interaction between high and low pressure legs of the circuit.
- The vent-to-shift function is self cleaning and therefore insensitive to contamination.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-31A |
| Series | 1 |
| Capacity | 15 gpm60 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Nominal Vent Flow | 23 in³/min.0,38 L/min. |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Model Weight | .35 lb0,15 kg |
| Seal kit - Cartridge | Viton: 990-031-006 |
