SUN HYDRAULICS
DSEOXCN
$182.97 USD
- SUN HYDRAULICS
- Material:DSEOXCN
- Model:DSEO-XCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSEOXCN (DSEOXCN) is a spring-offset, high-side shuttle cartridge valve designed for efficient hydraulic flow management. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 exceeds that of port 4, the cartridge shifts to connect the common port to port 2, blocking port 4. Despite being designed for a 4-port cavity, the nose port (port 1) remains unused. The valve incorporates Sun's floating style construction, which minimizes internal binding due to excessive installation torque or cavity-cartridge machining variations. It fits into a T-32A cavity and belongs to Series 2 with a capacity of up to 30 gpm (120 L/min). The maximum operating pressure is rated at 5000 psi (350 bar). Its hex size measures at 1-1/8 inches (28.6 mm), and it requires an installation torque between 45 and 50 lbf-ft (61 to 68 Nm). Weighing approximately .70 lb (.30 kg), this model comes with an optional Viton seal kit identified by part number: 990-032-006. The DSEOXCN is suitable for applications requiring reliable pressure management and can handle significant flow rates while maintaining stable operation under varying conditions.
The Sun Hydraulics DSEOXCN (DSEOXCN) is a spring-offset, high-side shuttle cartridge valve designed for efficient hydraulic flow management. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 exceeds that of port 4, the cartridge shifts to connect the common port to port 2, blocking port 4. Despite being designed for a 4-port cavity, the nose port (port 1) remains unused. The valve incorporates Sun's floating style construction, which minimizes internal binding due to excessive installation torque or cavity-cartridge machining variations. It fits into a T-32A cavity and belongs to Series 2 with a capacity of up to 30 gpm (120 L/min). The maximum operating pressure is rated at 5000 psi (350 bar). Its hex size measures at 1-1/8 inches (28.6 mm), and it requires an installation torque between 45 and 50 lbf-ft (61 to 68 Nm). Weighing approximately .70 lb (.30 kg), this model comes with an optional Viton seal kit identified by part number: 990-032-006. The DSEOXCN is suitable for applications requiring reliable pressure management and can handle significant flow rates while maintaining stable operation under varying conditions.
Spring-offset, high-side shuttle cartridges are 2-position valves that have a normal (offset) position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 rises above the pressure at port 4, the cartridge shifts to connect the common port to port 2 with port 4 then blocked.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-32A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .70 lb0,30 kg |
| Seal kit - Cartridge | Viton: 990-032-006 |
