SUN HYDRAULICS
DSEOXEV
$188.93 USD
- SUN HYDRAULICS
- Material:DSEOXEV
- Model:DSEO-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSEOXEV (DSEOXEV) is a spring-offset, high-side shuttle cartridge valve designed to manage fluid flow in hydraulic systems. This 2-position valve features a default state where the common port (port 3) is connected to work port 4, while work port 2 is blocked. When pressure at port 2 surpasses that at port 4, the valve shifts to connect the common port to port 2, blocking port 4. Notably, the nose port (port 1) remains unused despite the valve fitting into a four-port cavity. The DSEOXEV incorporates Sun's floating style construction, which reduces internal binding risks due to installation torque or machining variations. It fits in a T-32A cavity and belongs to series 2 with a capacity of up to 30 gpm (120 L/min). The maximum operating pressure for this model is rated at 5000 psi (350 bar). The valve has a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 and 50 lbf-ft (61 and 68 Nm). Weighing approximately .70 lb (.30 kg), it uses Viton seal kits for enhanced durability and performance. This cartridge valve is suitable for applications requiring reliable pressure management within hydraulic circuits, particularly where space constraints necessitate compact yet robust components.
The Sun Hydraulics DSEOXEV (DSEOXEV) is a spring-offset, high-side shuttle cartridge valve designed to manage fluid flow in hydraulic systems. This 2-position valve features a default state where the common port (port 3) is connected to work port 4, while work port 2 is blocked. When pressure at port 2 surpasses that at port 4, the valve shifts to connect the common port to port 2, blocking port 4. Notably, the nose port (port 1) remains unused despite the valve fitting into a four-port cavity. The DSEOXEV incorporates Sun's floating style construction, which reduces internal binding risks due to installation torque or machining variations. It fits in a T-32A cavity and belongs to series 2 with a capacity of up to 30 gpm (120 L/min). The maximum operating pressure for this model is rated at 5000 psi (350 bar). The valve has a hex size of 1-1/8 inches (28.6 mm) and requires an installation torque between 45 and 50 lbf-ft (61 and 68 Nm). Weighing approximately .70 lb (.30 kg), it uses Viton seal kits for enhanced durability and performance. This cartridge valve is suitable for applications requiring reliable pressure management within hydraulic circuits, particularly where space constraints necessitate compact yet robust components.
Spring-offset, high-side shuttle cartridges are 2-position valves that have a normal (offset) position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 rises above the pressure at port 4, the cartridge shifts to connect the common port to port 2 with port 4 then blocked.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-32A |
| Series | 2 |
| Capacity | 30 gpm120 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Model Weight | .70 lb0,30 kg |
| Seal kit - Cartridge | Viton: 990-032-006 |
