SUN HYDRAULICS
DSEYXCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSEYXCV (DSEYXCV) is a vent-to-shift diverter valve designed as a 2-position, 3-way cartridge that is normally open from port 3 to port 4. When port 1 is vented, the pressure differential between port 3 and port 1 exceeds the spring force, causing the valve to shift and connect port 3 to port 2. This valve is capable of modulating between these two positions and is not bistable. The vent flow out of port 1 is pressure compensated, requiring a pressure source at port 3 relative to port 1 for shifting. It can be used in pairs for selecting between two motors or pumps, with one pilot valve venting multiple diverter valves if blocking checks are used at each diverter's port 1. The self-cleaning vent-to-shift function makes it insensitive to contamination, while the hardened spool and sleeve ensure low leakage rates and excellent wear characteristics. The valve features Sun's floating style construction to prevent binding due to excessive installation torque or cavity/cartridge machining variations. It fits a T-32A cavity, belongs to Series 2, has a capacity of up to 30 gpm (120 L/min), and can operate at a maximum pressure of 5000 psi (350 bar). The nominal vent flow is rated at .23 in\u00b3/min (.38 L/min), with a hex size of 1-1/8 in (28.6 mm) and an installation torque requirement of 45-50 lbf ft (61-68 Nm). Weighing .70 lb (.30 kg), it uses Viton seal kits with part number 990032006 for cartridge sealing needs.
