SUN HYDRAULICS
DSEYXDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSEYXDV (DSEYXDV) is a 2-position, 3-way vent-to-shift diverter valve designed to be normally open from port 3 to port 4. This valve shifts to connect port 3 to port 2 when the pressure differential between port 3 and port 1 exceeds the spring force, and port 1 is vented. It features a modulating capability between its two positions and requires a pressure source at port 3 relative to port 1 for operation. The valve's self-cleaning vent-to-shift function ensures it remains insensitive to contamination. It can be used in pairs for selecting between two motors or pumps, with the option of using one pilot valve to vent multiple diverter valves if blocking checks are implemented at each diverter's port 1. The hardened spool and sleeve construction provide low spool leakage rates and excellent wear characteristics, while the Sun floating style construction minimizes internal binding risks due to installation torque or machining variations. This model fits into a T-32A cavity, supports a flow capacity of up to 30 gpm (120 L/min), and operates at a maximum pressure of 5000 psi (350 bar). It has a nominal vent flow of approximately 0.38 L/min (23 in\u00b3/min), with installation requiring a torque of between 45\u201350 lbf\u00b7ft (61\u201368 Nm). The DSEYXDV weighs approximately .70 lb (.30 kg) and uses Viton seal kits for maintenance.
