SUN HYDRAULICS
DSGOXCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSGOXCN (DSGOXCN) is a spring-offset, high-side shuttle cartridge valve designed for hydraulic applications requiring efficient flow direction control. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4, while blocking work port 2. When the pressure at port 2 surpasses that at port 4, the valve shifts to connect the common port to port 2, blocking port 4. Although designed for a 4-port cavity, the nose port (port 1) is not utilized in this model. The valve employs Sun's floating style construction, which reduces the risk of internal part binding due to excessive installation torque or variations in cavity/cartridge machining. The DSGOXCN fits into a T-33A cavity and belongs to Series 3 with a capacity of handling up to 60 gallons per minute (240 liters per minute). It can operate at a maximum pressure of 5000 psi (350 bar). The valve hex size measures at 1-1/4 inches (31.8 mm), and it requires an installation torque ranging from 150 to 160 lbf-ft (203 to 217 Nm). The model weighs approximately 1.40 lbs (0.65 kg) and uses Viton seals with cartridge seal kit number 990033006. This valve is particularly suitable for applications where reliable pressure management and flow control are critical. Its design makes it tolerant to dirt and stable under various conditions, offering robust performance in demanding settings.
