SUN HYDRAULICS
DSGOXCV
$332.10 USD
- SUN HYDRAULICS
- Material:DSGOXCV
- Model:DSGO-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSGOXCV (DSGOXCV) is a high-performance spring-offset, high-side shuttle cartridge valve designed for precise hydraulic control. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 exceeds that of port 4, the valve shifts to connect the common port to port 2 while blocking port 4. Although it fits into a 4-port cavity, the nose port (port 1) remains unused. The valve utilizes Sun's floating style construction, which helps minimize internal binding due to excessive installation torque or machining variations in the cavity and cartridge. The DSGOXCV is compatible with T-33A cavities and belongs to Series 3. It has a flow capacity of up to 60 gallons per minute (240 liters per minute) and can operate at a maximum pressure of 5000 psi (350 bar). The valve has a hex size of 1-1/4 inches (31.8 mm) and requires an installation torque between 150 and 160 lbf-ft (203 to 217 Nm). With a model weight of approximately 1.40 pounds (0.65 kg), it is built for robust performance in demanding applications. This cartridge is equipped with Viton seals, available as part number: Viton: 990033006. Designed for versatility, Sun's direct-acting valves are known for their rapid response times, dirt tolerance, stability, and durability, making them suitable for preventing overpressure situations. The pilot-operated valves offer moderate speed with easy adjustability and low pressure rise versus flow characteristics ideal for regulating pressure effectively in hydraulic systems.
The Sun Hydraulics DSGOXCV (DSGOXCV) is a high-performance spring-offset, high-side shuttle cartridge valve designed for precise hydraulic control. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 exceeds that of port 4, the valve shifts to connect the common port to port 2 while blocking port 4. Although it fits into a 4-port cavity, the nose port (port 1) remains unused. The valve utilizes Sun's floating style construction, which helps minimize internal binding due to excessive installation torque or machining variations in the cavity and cartridge. The DSGOXCV is compatible with T-33A cavities and belongs to Series 3. It has a flow capacity of up to 60 gallons per minute (240 liters per minute) and can operate at a maximum pressure of 5000 psi (350 bar). The valve has a hex size of 1-1/4 inches (31.8 mm) and requires an installation torque between 150 and 160 lbf-ft (203 to 217 Nm). With a model weight of approximately 1.40 pounds (0.65 kg), it is built for robust performance in demanding applications. This cartridge is equipped with Viton seals, available as part number: Viton: 990033006. Designed for versatility, Sun's direct-acting valves are known for their rapid response times, dirt tolerance, stability, and durability, making them suitable for preventing overpressure situations. The pilot-operated valves offer moderate speed with easy adjustability and low pressure rise versus flow characteristics ideal for regulating pressure effectively in hydraulic systems.
Spring-offset, high-side shuttle cartridges are 2-position valves that have a normal (offset) position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 rises above the pressure at port 4, the cartridge shifts to connect the common port to port 2 with port 4 then blocked.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-33A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.40 lb0,65 kg |
| Seal kit - Cartridge | Viton: 990-033-006 |
