SUN HYDRAULICS
DSGOXEV
$328.12 USD
- SUN HYDRAULICS
- Material:DSGOXEV
- Model:DSGO-XEV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSGOXEV (DSGOXEV) is a specialized spring-offset, high-side shuttle cartridge valve designed for applications requiring reliable control of hydraulic fluid flow. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When pressure at port 2 exceeds that at port 4, the cartridge shifts to connect the common port to port 2, blocking port 4 instead. The valve fits into a T-33A cavity but does not utilize the nose port (port 1). It incorporates Sun's floating style construction, which minimizes potential binding of internal parts due to excessive installation torque or variations in cavity and cartridge machining. The valve boasts a capacity of up to 60 gallons per minute (240 liters per minute) and can operate under a maximum pressure of 5000 psi (350 bar). Its hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150 and 160 lbf ft (203 to 217 Nm). Weighing in at just 1.40 lbs (0.65 kg), this model is compact yet robust, suitable for demanding hydraulic systems. For maintenance, it uses a Viton seal kit with the part number 990033006. This valve is ideal for systems needing precise control over fluid direction based on pressure changes, ensuring efficient operation in various hydraulic applications.
The Sun Hydraulics DSGOXEV (DSGOXEV) is a specialized spring-offset, high-side shuttle cartridge valve designed for applications requiring reliable control of hydraulic fluid flow. This 2-position valve features a normal offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When pressure at port 2 exceeds that at port 4, the cartridge shifts to connect the common port to port 2, blocking port 4 instead. The valve fits into a T-33A cavity but does not utilize the nose port (port 1). It incorporates Sun's floating style construction, which minimizes potential binding of internal parts due to excessive installation torque or variations in cavity and cartridge machining. The valve boasts a capacity of up to 60 gallons per minute (240 liters per minute) and can operate under a maximum pressure of 5000 psi (350 bar). Its hex size is 1-1/4 inches (31.8 mm), and it requires an installation torque between 150 and 160 lbf ft (203 to 217 Nm). Weighing in at just 1.40 lbs (0.65 kg), this model is compact yet robust, suitable for demanding hydraulic systems. For maintenance, it uses a Viton seal kit with the part number 990033006. This valve is ideal for systems needing precise control over fluid direction based on pressure changes, ensuring efficient operation in various hydraulic applications.
Spring-offset, high-side shuttle cartridges are 2-position valves that have a normal (offset) position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 rises above the pressure at port 4, the cartridge shifts to connect the common port to port 2 with port 4 then blocked.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-33A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.40 lb0,65 kg |
| Seal kit - Cartridge | Viton: 990-033-006 |
