SUN HYDRAULICS
DSGYXDV
$287.61 USD
- SUN HYDRAULICS
- Material:DSGYXDV
- Model:DSGY-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSGYXDV (DSGYXDV) is a vent-to-shift diverter valve designed as a 2-position, 3-way cartridge that is normally open from port 3 to port 4. This valve operates by venting port 1, which causes the pressure differential between port 3 and port 1 to exceed the spring force, thereby shifting the connection from port 3 to port 2. It is not bistable and can modulate between the two positions. The valve requires a pressure source at port 3 relative to port 1 for operation and features pressure-compensated vent flow out of port 1. A typical application includes using this valve in pairs to switch between two motors or pumps. For optimal performance, one pilot valve can vent multiple diverter valves if blocking checks are installed at each diverter's port 1; otherwise, interaction may occur between high and low-pressure circuit legs. The DSGYXDV is self-cleaning, making it resistant to contamination, and it incorporates hardened spool and sleeve components for consistent low spool leakage rates and excellent wear characteristics. Additionally, its floating style construction minimizes internal binding due to excessive installation torque or cavity/cartridge machining variations. It fits into a T-33A cavity and belongs to Series 3 with a capacity of up to 60 gpm (240 L/min) and a maximum operating pressure of 5000 psi (350 bar). The nominal vent flow is rated at approximately 35 in\u00b3/min (0.60 L/min). It features a hex size of 1-1/4 inches (31.8 mm) with an installation torque requirement ranging from 150 to 160 lbf-ft (203 to 217 Nm). The model weighs approximately 1.40 lb (0.65 kg), and Viton seal kits are available under part number 990033006 for maintenance needs.
The Sun Hydraulics DSGYXDV (DSGYXDV) is a vent-to-shift diverter valve designed as a 2-position, 3-way cartridge that is normally open from port 3 to port 4. This valve operates by venting port 1, which causes the pressure differential between port 3 and port 1 to exceed the spring force, thereby shifting the connection from port 3 to port 2. It is not bistable and can modulate between the two positions. The valve requires a pressure source at port 3 relative to port 1 for operation and features pressure-compensated vent flow out of port 1. A typical application includes using this valve in pairs to switch between two motors or pumps. For optimal performance, one pilot valve can vent multiple diverter valves if blocking checks are installed at each diverter's port 1; otherwise, interaction may occur between high and low-pressure circuit legs. The DSGYXDV is self-cleaning, making it resistant to contamination, and it incorporates hardened spool and sleeve components for consistent low spool leakage rates and excellent wear characteristics. Additionally, its floating style construction minimizes internal binding due to excessive installation torque or cavity/cartridge machining variations. It fits into a T-33A cavity and belongs to Series 3 with a capacity of up to 60 gpm (240 L/min) and a maximum operating pressure of 5000 psi (350 bar). The nominal vent flow is rated at approximately 35 in\u00b3/min (0.60 L/min). It features a hex size of 1-1/4 inches (31.8 mm) with an installation torque requirement ranging from 150 to 160 lbf-ft (203 to 217 Nm). The model weighs approximately 1.40 lb (0.65 kg), and Viton seal kits are available under part number 990033006 for maintenance needs.
This vent-to-shift diverter valve is a 2-position, 3-way cartridge that is normally open from port 3 to port 4. When port 1 is vented, the pressure differential between port 3 and port 1 exceeds the spring force causing the valve to shift, thereby connecting port 3 to port 2.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Vent flow out of port 1 is pressure compensated and is listed in Technical Data.
- There must be a pressure source at port 3, relative to port 1, to shift the valve.
- One application of this valve is to be used in pairs to select between 2 motors or pumps.
- One pilot valve may be used to vent multiple diverter valves if blocking checks are used at port 1 of each diverter. If blocking checks are not used there will be interaction between high and low pressure legs of the circuit.
- The vent-to-shift function is self cleaning and therefore insensitive to contamination.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-33A |
| Series | 3 |
| Capacity | 60 gpm240 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Nominal Vent Flow | 35 in³/min.0,60 L/min. |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Model Weight | 1.40 lb0,65 kg |
| Seal kit - Cartridge | Viton: 990-033-006 |
