SUN HYDRAULICS
DSIOXEN
$599.95 USD
- SUN HYDRAULICS
- Material:DSIOXEN
- Model:DSIO-XEN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSIOXEN (DSIOXEN) is a high-performance spring-offset, high-side shuttle cartridge valve designed for efficient hydraulic control. This 2-position valve features a default offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When the pressure at port 2 exceeds that of port 4, the cartridge shifts to connect the common port to port 2, subsequently blocking port 4. Notably, although this valve fits into a 4-port cavity, the nose port (port 1) remains unused. The design incorporates Sun's floating style construction, which minimizes potential internal binding from excessive installation torque or variations in cavity and cartridge machining. The DSIOXEN valve is built for a T-34A cavity and belongs to Series 4 with an impressive flow capacity of up to 120 gpm (480 L/min). It can withstand a maximum operating pressure of up to 5000 psi (350 bar). The valve has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque ranging between 350 and 375 lbf ft (475 - 508 Nm). With a model weight of approximately 2.90 lb (1.30 kg), it is robust yet manageable for various applications. This cartridge valve also comes with an available Viton seal kit under part number 990034006. It is suitable for applications requiring direct acting or pilot-operated valves, depending on specific needs such as overpressure prevention or pressure regulation. Direct acting valves are noted for their speed and robustness, while pilot-operated options offer moderate speed with easy adjustment capabilities.
The Sun Hydraulics DSIOXEN (DSIOXEN) is a high-performance spring-offset, high-side shuttle cartridge valve designed for efficient hydraulic control. This 2-position valve features a default offset position that connects the common port (port 3) to work port 4 while blocking work port 2. When the pressure at port 2 exceeds that of port 4, the cartridge shifts to connect the common port to port 2, subsequently blocking port 4. Notably, although this valve fits into a 4-port cavity, the nose port (port 1) remains unused. The design incorporates Sun's floating style construction, which minimizes potential internal binding from excessive installation torque or variations in cavity and cartridge machining. The DSIOXEN valve is built for a T-34A cavity and belongs to Series 4 with an impressive flow capacity of up to 120 gpm (480 L/min). It can withstand a maximum operating pressure of up to 5000 psi (350 bar). The valve has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque ranging between 350 and 375 lbf ft (475 - 508 Nm). With a model weight of approximately 2.90 lb (1.30 kg), it is robust yet manageable for various applications. This cartridge valve also comes with an available Viton seal kit under part number 990034006. It is suitable for applications requiring direct acting or pilot-operated valves, depending on specific needs such as overpressure prevention or pressure regulation. Direct acting valves are noted for their speed and robustness, while pilot-operated options offer moderate speed with easy adjustment capabilities.
Spring-offset, high-side shuttle cartridges are 2-position valves that have a normal (offset) position that connects the common port (port 3) to work port 4, with work port 2 blocked. When the pressure at port 2 rises above the pressure at port 4, the cartridge shifts to connect the common port to port 2 with port 4 then blocked.
- Although this valve goes into a 4-port cavity, the nose (port 1) is not used.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-34A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Model Weight | 2.90 lb1,30 kg |
| Seal kit - Cartridge | Viton: 990-034-006 |
