SUN HYDRAULICS
DSIXXCN
$560.33 USD
- SUN HYDRAULICS
- Material:DSIXXCN
- Model:DSIX-XCN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSIXCN (DSIXXCN) is a vent-to-shift, 2-position diverter valve that operates in a normally closed state. Upon venting port 1, the pressure differential between port 3 and port 1 surpasses the spring force, shifting the valve to connect port 3 with ports 2 and 4. This valve is not bistable and can modulate between two positions. It features pressure-compensated vent flow out of port 1. A pressure source at port 3 relative to port 1 is required to shift the valve. An application for this valve includes bypassing divider-combiner valves in limited-slip tractive circuits; when closed, oil flows through divider-combiner valves, and when open, it provides a large path around them for efficient high-speed operation. A single pilot valve can vent multiple diverter valves if blocking checks are used at each diverter's port 1; otherwise, interaction occurs between high and low-pressure circuit legs. The vent-to-shift function is self-cleaning and insensitive to contamination. It incorporates a hardened spool and sleeve for consistent low spool leakage rates and excellent wear characteristics while using Sun's floating style construction to minimize internal part binding risks due to excessive installation torque or cavity/cartridge machining variations. The valve fits into cavity T-34A, belongs to series 4, has a capacity of up to 120 gpm (480 L/min), operates at a maximum pressure of 5000 psi (350 bar), with a nominal vent flow of 35 in\u00b3/min (0.60 L/min). The hex size is 1-5/8 inches (41.3 mm), with an installation torque of 350 - 375 lbf ft (475 - 508 Nm). The model weighs approximately 3.30 lb (1.50 kg) and uses Viton seal kit number: 990034006 for maintenance purposes.
The Sun Hydraulics DSIXCN (DSIXXCN) is a vent-to-shift, 2-position diverter valve that operates in a normally closed state. Upon venting port 1, the pressure differential between port 3 and port 1 surpasses the spring force, shifting the valve to connect port 3 with ports 2 and 4. This valve is not bistable and can modulate between two positions. It features pressure-compensated vent flow out of port 1. A pressure source at port 3 relative to port 1 is required to shift the valve. An application for this valve includes bypassing divider-combiner valves in limited-slip tractive circuits; when closed, oil flows through divider-combiner valves, and when open, it provides a large path around them for efficient high-speed operation. A single pilot valve can vent multiple diverter valves if blocking checks are used at each diverter's port 1; otherwise, interaction occurs between high and low-pressure circuit legs. The vent-to-shift function is self-cleaning and insensitive to contamination. It incorporates a hardened spool and sleeve for consistent low spool leakage rates and excellent wear characteristics while using Sun's floating style construction to minimize internal part binding risks due to excessive installation torque or cavity/cartridge machining variations. The valve fits into cavity T-34A, belongs to series 4, has a capacity of up to 120 gpm (480 L/min), operates at a maximum pressure of 5000 psi (350 bar), with a nominal vent flow of 35 in\u00b3/min (0.60 L/min). The hex size is 1-5/8 inches (41.3 mm), with an installation torque of 350 - 375 lbf ft (475 - 508 Nm). The model weighs approximately 3.30 lb (1.50 kg) and uses Viton seal kit number: 990034006 for maintenance purposes.
This is a vent-to-shift, 2-position, diverter valve that is normally closed. When port 1 is vented, the pressure differential between port 3 and port 1 exceeds the spring force causing the valve to shift, thereby connecting port 3 with ports 2 and 4.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Vent flow out of port 1 is pressure compensated and is listed in Technical Data.
- There must be a pressure source at port 3, relative to port 1, to shift the valve.
- One application of this valve is to bypass divider/combiner valves in a limited-slip tractive circuit. Closed, the oil must go through the divider/combiner valves. Open, there is a large path around the divider/combiner valves for efficient high speed operation.
- One pilot valve may be used to vent multiple diverter valves if blocking checks are used at port 1 of each diverter. If blocking checks are not used there will be interaction between high and low pressure legs of the circuit.
- The vent-to-shift function is self cleaning and therefore insensitive to contamination.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-34A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Nominal Vent Flow | 35 in³/min.0,60 L/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Model Weight | 3.30 lb1,50 kg |
| Seal kit - Cartridge | Viton: 990-034-006 |
