SUN HYDRAULICS
DSIYXCV
$569.27 USD
- SUN HYDRAULICS
- Material:DSIYXCV
- Model:DSIY-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics DSIYXCV (DSIYXCV) is a vent-to-shift diverter valve designed for hydraulic systems requiring efficient flow management. This 2-position, 3-way cartridge valve is typically open from port 3 to port 4 and shifts to connect port 3 to port 2 when the pressure differential between ports 3 and 1 surpasses the spring force. Notably, it is not bistable and can modulate between its two positions. The valve's vent flow out of port 1 is pressure compensated, ensuring stable operation under varying conditions, with technical data available for precise specifications. This diverter valve requires a pressure source at port 3 relative to port 1 for operation, making it suitable for applications such as selecting between two motors or pumps when used in pairs. A single pilot valve can vent multiple diverter valves if blocking checks are installed at each diverter's port 1; otherwise, interactions may occur between high and low-pressure circuits. Its self-cleaning vent-to-shift function enhances reliability by reducing sensitivity to contamination. Constructed with a hardened spool and sleeve, the DSIYXCV offers low spool leakage rates and excellent wear characteristics. The Sun floating style construction minimizes internal part binding risks due to excessive installation torque or machining variations in the cavity/cartridge. The valve fits into a T-34A cavity with a series capacity of up to 120 gpm (480 L/min) and can withstand maximum operating pressures of up to 5000 psi (350 bar). It features a nominal vent flow of approximately 35 in\u00b3/min (0.60 L/min), requires an installation torque of about 350-375 lbf-ft (475-508 Nm), and weighs approximately 3.30 lb (1.50 kg). This robust design makes it an ideal choice for demanding hydraulic applications requiring reliable performance and longevity.
The Sun Hydraulics DSIYXCV (DSIYXCV) is a vent-to-shift diverter valve designed for hydraulic systems requiring efficient flow management. This 2-position, 3-way cartridge valve is typically open from port 3 to port 4 and shifts to connect port 3 to port 2 when the pressure differential between ports 3 and 1 surpasses the spring force. Notably, it is not bistable and can modulate between its two positions. The valve's vent flow out of port 1 is pressure compensated, ensuring stable operation under varying conditions, with technical data available for precise specifications. This diverter valve requires a pressure source at port 3 relative to port 1 for operation, making it suitable for applications such as selecting between two motors or pumps when used in pairs. A single pilot valve can vent multiple diverter valves if blocking checks are installed at each diverter's port 1; otherwise, interactions may occur between high and low-pressure circuits. Its self-cleaning vent-to-shift function enhances reliability by reducing sensitivity to contamination. Constructed with a hardened spool and sleeve, the DSIYXCV offers low spool leakage rates and excellent wear characteristics. The Sun floating style construction minimizes internal part binding risks due to excessive installation torque or machining variations in the cavity/cartridge. The valve fits into a T-34A cavity with a series capacity of up to 120 gpm (480 L/min) and can withstand maximum operating pressures of up to 5000 psi (350 bar). It features a nominal vent flow of approximately 35 in\u00b3/min (0.60 L/min), requires an installation torque of about 350-375 lbf-ft (475-508 Nm), and weighs approximately 3.30 lb (1.50 kg). This robust design makes it an ideal choice for demanding hydraulic applications requiring reliable performance and longevity.
This vent-to-shift diverter valve is a 2-position, 3-way cartridge that is normally open from port 3 to port 4. When port 1 is vented, the pressure differential between port 3 and port 1 exceeds the spring force causing the valve to shift, thereby connecting port 3 to port 2.
- This valve is not bistable; it is capable of modulating between the two positions shown.
- Vent flow out of port 1 is pressure compensated and is listed in Technical Data.
- There must be a pressure source at port 3, relative to port 1, to shift the valve.
- One application of this valve is to be used in pairs to select between 2 motors or pumps.
- One pilot valve may be used to vent multiple diverter valves if blocking checks are used at port 1 of each diverter. If blocking checks are not used there will be interaction between high and low pressure legs of the circuit.
- The vent-to-shift function is self cleaning and therefore insensitive to contamination.
- Hardened spool and sleeve provide consistent and low spool leakage rates and excellent wear characteristics.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-34A |
| Series | 4 |
| Capacity | 120 gpm480 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Nominal Vent Flow | 35 in³/min.0,60 L/min. |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Model Weight | 3.30 lb1,50 kg |
| Seal kit - Cartridge | Viton: 990-034-006 |
