SUN HYDRAULICS
EHC

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics EHC (Material Number: EHC) is a line mount hydraulic manifold designed for efficient fluid control in hydraulic systems. This manifold features a through port with an additional gauge port, allowing for precise monitoring of hydraulic pressure. It includes two mounting holes with a thread size of .375-16 UNC 2B and a depth of .62 inches (15.7 mm), providing secure installation options. The manifold accommodates one open cavity, designated as T-11A, and has a port size of 1/2 NPTF, which is suitable for various hydraulic applications requiring robust connections. Constructed from 6061-T651 aluminum, the EHC manifold offers excellent corrosion resistance and durability under demanding conditions. While not anodized, the material choice ensures that the manifold can withstand typical environmental challenges without compromising performance or longevity. This makes it ideal for use in systems where reliability and maintenance-free operation are critical. The Sun Hydraulics EHC manifold is specifically designed to handle maximum system pressures up to 3000 psi (210 bar), making it suitable for high-pressure hydraulic applications. However, users should carefully consider system pressure requirements and ensure compatibility with the manifold's pressure rating to maintain safety and performance standards. Overall, the Sun Hydraulics EHC line mount manifold provides a reliable solution for integrating high-flow valves into hydraulic systems while offering ease of installation and maintenance due to its thoughtful design features.
