SUN HYDRAULICS
EIU

$124.20 USD

SUN HYDRAULICS
Material:EIU
Summary:Manifold

Quantity in stock: 0

Note: Sales tax, and shipping will be calculated at checkout.

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics EIU (Material Number: EIU) is a line mount hydraulic manifold designed for applications requiring a 2-cylinder sequence with direct acting functionality. This product features a body type suitable for line mounting without any additional interface requirements. It includes two open cavities, specifically designed to fit the T11A cavity size, and accommodates port sizes of 3/8 BSPP. The manifold is equipped with two mounting holes, each with a diameter of 0.34 inches (8.6 mm), extending through the body for secure attachment. Constructed from 6061 T651 aluminum, the EIU manifold offers excellent corrosion resistance without the need for anodizing, thus maintaining its structural integrity and longevity even in challenging environments. This material choice ensures that the manifold remains lightweight yet durable enough to handle pressures up to 3000 psi (210 bar). The design does not include anodizing, which helps to avoid issues related to fatigue life reduction and increased breakaway torque commonly associated with anodized surfaces. The Sun Hydraulics EIU manifold is ideal for systems where precise control over sequential cylinder operations is necessary, making it suitable for various hydraulic applications that demand reliable performance and ease of installation. Its robust construction and thoughtful engineering make it a dependable choice for ensuring efficient hydraulic system operations while minimizing maintenance concerns related to material fatigue or corrosion.

Description

Body Type	Line mountLine mount
Interface	NoneNone
Body Features	2 cylinder sequence, direct acting2 cylinder sequence, direct acting
Mounting Hole Diameter	.34 in.8.6 mm
Mounting Hole Depth	ThroughThrough
Mounting Hole Quantity	22
Open Cavities	22
Cavity	T-11A
Port Size	3/8" BSPP3/8" BSPP

Show FAQ

How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.
Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
