SUN HYDRAULICS
ELV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics ELV (Material Number: ELV) is a line mount hydraulic manifold designed for high capacity applications. This model features a ninety-degree body with a high capacity port 3 and an additional gauge port, making it suitable for complex hydraulic systems requiring efficient flow management. It has a mounting hole diameter of 0.34 inches (8.6 mm) and a through-hole depth, accommodating up to two mounting holes. The manifold supports one open cavity of type T11A and utilizes 12 BSPP port sizes for versatile connectivity. Constructed from 6061T651 aluminum, the ELV manifold offers excellent corrosion resistance without the need for anodizing, which can compromise fatigue life and increase costs. The design ensures reliable performance in environments where pressure does not exceed 3000 psi (210 bar), as aluminum manifolds are limited by this pressure threshold regardless of port size. This makes it ideal for applications where durability and material integrity are critical under moderate pressure conditions. The ELV model's configuration allows for seamless integration into existing systems using standard line mount interfaces, providing flexibility in system design and maintenance. Its robust construction supports efficient hydraulic flow control, making it an essential component in systems requiring precise fluid management and distribution.
