SUN HYDRAULICS
FCCBKAN
$128.87 USD
- SUN HYDRAULICS
- Material:FCCBKAN
- Model:FCCB-KAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FCCBKAN (Material Number: FCCBKAN) is a fixed-orifice, pressure-compensated flow control valve designed for precise flow regulation in applications with significant pressure fluctuations. This model features an integral high-capacity check valve that allows unrestricted flow from port 2 to port 1, making it suitable for both meter-in and meter-out applications. The flow setting is factory-set based on customer specifications, with a precision range of within 10% of the requested setting. The sharp-edged orifice design is engineered to minimize variations due to viscosity changes, ensuring consistent performance across different fluid conditions. Additionally, the tuneable control option allows for a 25% variation from the nominal factory preset flow by adjusting clockwise to increase flow. This cartridge valve is part of the Series 1 and fits into a T-13A cavity. It has a capacity of up to 6 gpm (23 L/min) and can operate at a maximum pressure of 5000 psi (350 bar). The valve's hex size is 7/8 inches (22.2 mm), with an installation torque requirement between 30 and 35 lbf ft (41-47 Nm). The adjustment screw features an internal hex size of 5/32 inches (4 mm), while the locknut requires a hex size of 9/16 inches (15 mm) and torque between 80 and 90 lbf in (9-10 Nm). Weighing only .30 lbs (.15 kg), this lightweight valve also incorporates Sun\u2019s floating style construction to reduce the risk of internal parts binding due to excessive installation torque or machining variations. This corrosion-resistant cartridge can be customized with external stainless steel components or zinc-nickel plating, designated by model code suffixes AP or LH respectively. This makes it ideal for use in corrosive environments while maintaining reliable performance.
The Sun Hydraulics FCCBKAN (Material Number: FCCBKAN) is a fixed-orifice, pressure-compensated flow control valve designed for precise flow regulation in applications with significant pressure fluctuations. This model features an integral high-capacity check valve that allows unrestricted flow from port 2 to port 1, making it suitable for both meter-in and meter-out applications. The flow setting is factory-set based on customer specifications, with a precision range of within 10% of the requested setting. The sharp-edged orifice design is engineered to minimize variations due to viscosity changes, ensuring consistent performance across different fluid conditions. Additionally, the tuneable control option allows for a 25% variation from the nominal factory preset flow by adjusting clockwise to increase flow. This cartridge valve is part of the Series 1 and fits into a T-13A cavity. It has a capacity of up to 6 gpm (23 L/min) and can operate at a maximum pressure of 5000 psi (350 bar). The valve's hex size is 7/8 inches (22.2 mm), with an installation torque requirement between 30 and 35 lbf ft (41-47 Nm). The adjustment screw features an internal hex size of 5/32 inches (4 mm), while the locknut requires a hex size of 9/16 inches (15 mm) and torque between 80 and 90 lbf in (9-10 Nm). Weighing only .30 lbs (.15 kg), this lightweight valve also incorporates Sun\u2019s floating style construction to reduce the risk of internal parts binding due to excessive installation torque or machining variations. This corrosion-resistant cartridge can be customized with external stainless steel components or zinc-nickel plating, designated by model code suffixes AP or LH respectively. This makes it ideal for use in corrosive environments while maintaining reliable performance.
Fixed-orifice, pressure-compensated flow controls with reverse-flow check provide precise flow regulation for meter-in or meter-out applications where there may be wide pressure fluctuations. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1. The flow setting is specified by the user and is set at the factory.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- The tuneable control option provides +/- 25% variation from the nominal factory pre-set flow. Turn the adjustment clockwise to increase.
- All 2-port flow control cartridges are physically and functionally interchangeable (i.e. same flow path, same cavity for a given frame size). However, cartridge extension dimensions from the mounting surface may vary.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP for external stainless steel components, or /LH for external zinc-nickel plated components. See the CONFIGURATION section for all options. For further details, please see the Materials of Construction page located under TECH RESOURCES.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 6 gpm23 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .30 lb0,15 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
