SUN HYDRAULICS
FCDBRBN
$190.52 USD
- SUN HYDRAULICS
- Material:FCDBRBN
- Model:FCDB-RBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FCDBRBN (Material Number: FCDBRBN) is a fixed orifice, pressure-compensated flow control valve designed to provide precise flow regulation for applications requiring meter-in or meter-out flow control, even under wide pressure fluctuations. This model features an integral high-capacity check valve that allows unrestricted flow from port 2 to port 1. The flow setting is user-specified and factory-set with an accuracy within 10% of the requested setting. The valve's sharp-edged orifice design minimizes variations in flow due to changes in fluid viscosity, ensuring consistent performance. Additionally, the tuneable control option allows for a \u00b125% adjustment from the nominal factory preset flow by turning the adjustment clockwise to increase the flow rate. This model incorporates Sun's floating style construction, which helps prevent internal parts from binding due to excessive installation torque or variations in cavity and cartridge machining. It is compatible with T5A cavities and has a capacity of 12 gpm (45 L/min) with a maximum operating pressure of 5000 psi (350 bar). The valve features corrosion-resistant options identified by specific model code suffixes for environments requiring enhanced durability. Installation specifications include a valve hex size of 1-1/8 inches (28.6 mm), an installation torque range of 45-50 lbf\u00b7ft (61-68 Nm), and an adjustment screw internal hex size of 5/32 inches (4 mm). The locknut hex size is 9/16 inches (15 mm) with a torque specification of 80-90 lbf\u00b7in (9-10 Nm). The model weighs approximately .50 lb (.25 kg) and uses Viton seal kits for cartridge applications. This product is ideal for maintaining accurate flow control in hydraulic systems where precision and reliability are critical.
The Sun Hydraulics FCDBRBN (Material Number: FCDBRBN) is a fixed orifice, pressure-compensated flow control valve designed to provide precise flow regulation for applications requiring meter-in or meter-out flow control, even under wide pressure fluctuations. This model features an integral high-capacity check valve that allows unrestricted flow from port 2 to port 1. The flow setting is user-specified and factory-set with an accuracy within 10% of the requested setting. The valve's sharp-edged orifice design minimizes variations in flow due to changes in fluid viscosity, ensuring consistent performance. Additionally, the tuneable control option allows for a \u00b125% adjustment from the nominal factory preset flow by turning the adjustment clockwise to increase the flow rate. This model incorporates Sun's floating style construction, which helps prevent internal parts from binding due to excessive installation torque or variations in cavity and cartridge machining. It is compatible with T5A cavities and has a capacity of 12 gpm (45 L/min) with a maximum operating pressure of 5000 psi (350 bar). The valve features corrosion-resistant options identified by specific model code suffixes for environments requiring enhanced durability. Installation specifications include a valve hex size of 1-1/8 inches (28.6 mm), an installation torque range of 45-50 lbf\u00b7ft (61-68 Nm), and an adjustment screw internal hex size of 5/32 inches (4 mm). The locknut hex size is 9/16 inches (15 mm) with a torque specification of 80-90 lbf\u00b7in (9-10 Nm). The model weighs approximately .50 lb (.25 kg) and uses Viton seal kits for cartridge applications. This product is ideal for maintaining accurate flow control in hydraulic systems where precision and reliability are critical.
Fixed-orifice, pressure-compensated flow controls with reverse-flow check provide precise flow regulation for meter-in or meter-out applications where there may be wide pressure fluctuations. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1. The flow setting is specified by the user and is set at the factory.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- All 2-port flow control cartridges are physically and functionally interchangeable (i.e. same flow path, same cavity for a given frame size). However, cartridge extension dimensions from the mounting surface may vary.
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- The tuneable control option provides +/- 25% variation from the nominal factory pre-set flow. Turn the adjustment clockwise to increase.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP for external stainless steel components, or /LH for external zinc-nickel plated components. See the CONFIGURATION section for all options. For further details, please see the Materials of Construction page located under TECH RESOURCES.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 12 gpm45 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .50 lb0,25 kg |
| Seal kit - Cartridge | Viton: 990-203-006 |
