SUN HYDRAULICS
FCEBKAN
$220.31 USD
- SUN HYDRAULICS
- Material:FCEBKAN
- Model:FCEB-KAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FCEBKAN (FCEBKAN) is a fixed orifice, pressure-compensated flow control valve with a reverse flow check, designed for precise flow regulation in meter-in or meter-out applications that experience wide pressure fluctuations. This product features an integral high-capacity check valve allowing unrestricted flow from port 2 to port 1. Users specify the flow setting, which is factory-set within a 10% margin of the requested rate. The sharp-edged orifice design minimizes variations due to viscosity changes, ensuring consistent performance across different conditions. All two-port flow control cartridges are interchangeable in terms of flow path and cavity size for the same frame size, although extension dimensions may vary. This model offers a tuneable control option providing up to 22% variation from the nominal factory preset flow by turning the adjustment clockwise to increase flow. It incorporates corrosion-resistant materials identified by specific model code suffixes for use in corrosive environments. The Sun floating style construction minimizes internal parts binding caused by excessive installation torque or machining variations. The FCEBKAN fits into a T-16A cavity and belongs to Series 3 with a capacity of 25 gpm (95 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). The valve has a hex size of 1-1/4 inches (31.8 mm) and requires an installation torque of between 150 and 160 lbf ft (203 - 217 Nm). The adjustment screw has an internal hex size of 5/32 inches (4 mm), while the locknut has a hex size of 9/16 inches (15 mm) with a torque requirement of between 80 and 90 lbf in (9 - 10 Nm). The model weighs approximately 1 lb (0.45 kg) and uses Viton seal kits for enhanced durability.
The Sun Hydraulics FCEBKAN (FCEBKAN) is a fixed orifice, pressure-compensated flow control valve with a reverse flow check, designed for precise flow regulation in meter-in or meter-out applications that experience wide pressure fluctuations. This product features an integral high-capacity check valve allowing unrestricted flow from port 2 to port 1. Users specify the flow setting, which is factory-set within a 10% margin of the requested rate. The sharp-edged orifice design minimizes variations due to viscosity changes, ensuring consistent performance across different conditions. All two-port flow control cartridges are interchangeable in terms of flow path and cavity size for the same frame size, although extension dimensions may vary. This model offers a tuneable control option providing up to 22% variation from the nominal factory preset flow by turning the adjustment clockwise to increase flow. It incorporates corrosion-resistant materials identified by specific model code suffixes for use in corrosive environments. The Sun floating style construction minimizes internal parts binding caused by excessive installation torque or machining variations. The FCEBKAN fits into a T-16A cavity and belongs to Series 3 with a capacity of 25 gpm (95 L/min) and can withstand a maximum operating pressure of 5000 psi (350 bar). The valve has a hex size of 1-1/4 inches (31.8 mm) and requires an installation torque of between 150 and 160 lbf ft (203 - 217 Nm). The adjustment screw has an internal hex size of 5/32 inches (4 mm), while the locknut has a hex size of 9/16 inches (15 mm) with a torque requirement of between 80 and 90 lbf in (9 - 10 Nm). The model weighs approximately 1 lb (0.45 kg) and uses Viton seal kits for enhanced durability.
Fixed-orifice, pressure-compensated flow controls with reverse-flow check provide precise flow regulation for meter-in or meter-out applications where there may be wide pressure fluctuations. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1. The flow setting is specified by the user and is set at the factory.
- Customer must specify a flow rating. Factory set flow ratings are within +/- 10% of the requested setting.
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- All 2-port flow control cartridges are physically and functionally interchangeable (i.e. same flow path, same cavity for a given frame size). However, cartridge extension dimensions from the mounting surface may vary.
- The tuneable control option provides +/- 22% variation from the nominal factory pre-set flow. Turn the adjustment clockwise to increase.
- Corrosion resistant cartridge valves are intended for use in corrosive environments and are identified by the model code suffix /AP for external stainless steel components, or /LH for external zinc-nickel plated components. See the CONFIGURATION section for all options. For further details, please see the Materials of Construction page located under TECH RESOURCES.
- Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 25 gpm95 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | 1.00 lb0,45 kg |
| Seal kit - Cartridge | Viton: 990-016-006 |
