SUN HYDRAULICS
FDBALBE
$413.11 USD
- SUN HYDRAULICS
- Material:FDBALBE
- Model:FDBA-LBE
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FDBALBE (Material Number: FDBALBE) is a fully adjustable, pressure-compensated flow control valve with a reverse-flow check feature designed for precise flow regulation in both meter-in and meter-out applications. This model is particularly effective in scenarios where there are significant pressure fluctuations. The valve allows for infinite adjustment from nearly closed to the maximum flow rate of 6 gpm (23 L/min). It includes an integral high-capacity check valve that ensures unrestricted flow from port 2 to port 1. All two-port flow control cartridges, including this model, are physically and functionally interchangeable, meaning they share the same flow path and cavity for a given frame size, although cartridge extension dimensions may vary. The balanced adjustment mechanism facilitates easy adjustments even at high pressures, and its sharp-edged orifice design minimizes variations in flow due to changes in viscosity. With minimal leakage of .1 gpm (0.4 L/min) when fully shut off, this cartridge is highly efficient. This particular model fits into a T-13A cavity and belongs to Series 1 with a maximum operating pressure of 5000 psi (350 bar). The adjustment mechanism allows up to 5.5 counterclockwise turns from fully closed to fully open positions. Installation requires a valve hex size of 7/8 inch (22.2 mm) with a torque specification between 30 - 35 lbf-ft (41 - 47 Nm). Additionally, it features an internal hex size for the adjustment screw at 5/32 inch (4 mm), and the locknut requires a hex size of 9/16 inch (15 mm) with a torque range of 80 - 90 lbf-in (9 - 10 Nm). For systems using phosphate ester fluids, cartridges with EPDM seals are recommended as exposure to petroleum-based fluids will damage these seals.
The Sun Hydraulics FDBALBE (Material Number: FDBALBE) is a fully adjustable, pressure-compensated flow control valve with a reverse-flow check feature designed for precise flow regulation in both meter-in and meter-out applications. This model is particularly effective in scenarios where there are significant pressure fluctuations. The valve allows for infinite adjustment from nearly closed to the maximum flow rate of 6 gpm (23 L/min). It includes an integral high-capacity check valve that ensures unrestricted flow from port 2 to port 1. All two-port flow control cartridges, including this model, are physically and functionally interchangeable, meaning they share the same flow path and cavity for a given frame size, although cartridge extension dimensions may vary. The balanced adjustment mechanism facilitates easy adjustments even at high pressures, and its sharp-edged orifice design minimizes variations in flow due to changes in viscosity. With minimal leakage of .1 gpm (0.4 L/min) when fully shut off, this cartridge is highly efficient. This particular model fits into a T-13A cavity and belongs to Series 1 with a maximum operating pressure of 5000 psi (350 bar). The adjustment mechanism allows up to 5.5 counterclockwise turns from fully closed to fully open positions. Installation requires a valve hex size of 7/8 inch (22.2 mm) with a torque specification between 30 - 35 lbf-ft (41 - 47 Nm). Additionally, it features an internal hex size for the adjustment screw at 5/32 inch (4 mm), and the locknut requires a hex size of 9/16 inch (15 mm) with a torque range of 80 - 90 lbf-in (9 - 10 Nm). For systems using phosphate ester fluids, cartridges with EPDM seals are recommended as exposure to petroleum-based fluids will damage these seals.
Fully adjustable, pressure-compensated flow controls with reverse-flow check provide precise flow regulation for meter-in or meter-out applications where there may be wide pressure fluctuations. They are infinitely adjustable from nearly closed up to the maximum flow. An integral high-capacity check valve provides unrestricted flow from port 2 to port 1.
- All 2-port flow control cartridges are physically and functionally interchangeable (i.e. same flow path, same cavity for a given frame size). However, cartridge extension dimensions from the mounting surface may vary.
- A balanced adjustment mechanism allows for easy adjustment even at high pressures.
- The sharp-edged orifice design minimizes flow variations due to viscosity changes.
- Minimum leakage is .1 gpm (0,4 L/min) when the adjustment mechanism is turned to the shut-off position.
- Cartridges with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
| Cavity | T-13A |
| Series | 1 |
| Capacity | 6 gpm23 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Adjustment - Number of Counterclockwise Turns - Fully Closed to Fully Open | 55 |
| Valve Hex Size | 7/8 in.22,2 mm |
| Valve Installation Torque | 30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size | 5/32 in.4 mm |
| Locknut Hex Size | 9/16 in.15 mm |
| Locknut Torque | 80 - 90 lbf in.9 - 10 Nm |
| Model Weight | .40 lb0,20 kg |
| Seal kit - Cartridge | Viton: 990-010-006 |
