SUN HYDRAULICS
FDCBYAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FDCBYAV (Material Number: FDCBYAV) is a fully adjustable, pressure-compensated flow control valve designed to provide precise flow regulation for both meter-in and meter-out applications, especially in scenarios with wide pressure fluctuations. This model features a reverse-flow check that allows for unrestricted flow from port 2 to port 1, thanks to its integral high-capacity check valve. With its balanced adjustment mechanism, the valve can be easily adjusted even under high pressures. The sharp-edged orifice design minimizes flow variations due to changes in fluid viscosity, while the minimum leakage rate is .2 gpm (0.8 L/min) when the adjustment mechanism is fully closed. Physically and functionally interchangeable with other 2-port flow control cartridges of the same frame size, this model uses a T5A cavity and belongs to Series 2 with a capacity of 12 gpm (45 L/min). It can withstand a maximum operating pressure of 5000 psi (350 bar). The adjustment range spans up to 5.5 counterclockwise turns from fully closed to fully open. Installation requires a torque of 45-50 lbf ft (61-68 Nm), and the valve hex size is 1-1/8 inches (28.6 mm). The locknut hex size is 9/16 inches (15 mm), requiring a torque of 80-90 lbf in (9-10 Nm). This model weighs approximately .60 lb (0.30 kg) and can be fitted with Viton seals using seal kit number 990203006 for use with phosphate ester fluids; however, exposure to petroleum-based fluids should be avoided as it may damage the seals. This product is ideal for applications requiring consistent flow control under varying conditions, ensuring system efficiency and reliability.
