SUN HYDRAULICS
FLFAXDN
$290.10 USD
- SUN HYDRAULICS
- Material:FLFAXDN
- Model:FLFA-XDN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLFAXDN (Material Number: FLFAXDN) is a high-performance filter element designed for hydraulic systems requiring robust filtration solutions. It features a surface type design with a 304 stainless steel mesh media, ensuring durability and resistance to corrosion. The filter is engineered to handle a differential crush pressure of up to 3000 psid (210 bar) and operates effectively with a maximum operating pressure of 5000 psi (350 bar). With its flow path restricted from Port 2 to Port 1, it should not be used in reverse, even if a reverse free flow check valve is installed. This configuration makes it suitable for protecting the entire valve stack from potential contaminants when installed directly above the subplate. The FLFAXDN has a nominal rating of 40 microns and an absolute rating of 63 microns, making it adept at capturing errant particles that might bypass the main system filter or result from component failures. Its single-layer stainless steel mesh supported by a perforated sheet tube provides additional structural integrity. Designed for seamless integration into existing systems, this element boasts an impressive capacity of 20 gpm (80 L/min) and fits into the T5A cavity series with ease. Installation requires adherence to specific torque settings, with a valve hex size of 1-1/8 inches (28.6 mm) and installation torque between 45-50 lbf-ft (61-68 Nm). The use of Viton seal kits ensures reliable performance under varying conditions. The Sun Hydraulics FLFAXDN offers dependable protection for hydraulic systems, enhancing operational efficiency by minimizing the risk of particle-induced damage or failure.
The Sun Hydraulics FLFAXDN (Material Number: FLFAXDN) is a high-performance filter element designed for hydraulic systems requiring robust filtration solutions. It features a surface type design with a 304 stainless steel mesh media, ensuring durability and resistance to corrosion. The filter is engineered to handle a differential crush pressure of up to 3000 psid (210 bar) and operates effectively with a maximum operating pressure of 5000 psi (350 bar). With its flow path restricted from Port 2 to Port 1, it should not be used in reverse, even if a reverse free flow check valve is installed. This configuration makes it suitable for protecting the entire valve stack from potential contaminants when installed directly above the subplate. The FLFAXDN has a nominal rating of 40 microns and an absolute rating of 63 microns, making it adept at capturing errant particles that might bypass the main system filter or result from component failures. Its single-layer stainless steel mesh supported by a perforated sheet tube provides additional structural integrity. Designed for seamless integration into existing systems, this element boasts an impressive capacity of 20 gpm (80 L/min) and fits into the T5A cavity series with ease. Installation requires adherence to specific torque settings, with a valve hex size of 1-1/8 inches (28.6 mm) and installation torque between 45-50 lbf-ft (61-68 Nm). The use of Viton seal kits ensures reliable performance under varying conditions. The Sun Hydraulics FLFAXDN offers dependable protection for hydraulic systems, enhancing operational efficiency by minimizing the risk of particle-induced damage or failure.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
