SUN HYDRAULICS
FLFAXDV
$296.55 USD
- SUN HYDRAULICS
- Material:FLFAXDV
- Model:FLFA-XDV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLFAXDV (FLFAXDV) is a highly specialized filter element designed for hydraulic systems, providing crucial protection against errant particles that may bypass the main system filter or result from component failures. This Surface Type Last Chance element features a 304 stainless steel mesh media, with all internal components also made of 304 stainless steel, ensuring durability and longevity. The filter has a nominal rating of 40 microns and an absolute rating of 63 microns, making it effective in capturing fine particles. The differential crush pressure is rated at 3000 psid (210 bar), demonstrating its robustness under high-pressure conditions. The flow path is strictly from Port 2 to Port 1, and it should not be reversed even with a reverse free flow check valve installed. This ensures optimal performance and protection for the entire valve stack when installed directly above the subplate. With a capacity of handling up to 20 gpm (80 L/min) and a maximum operating pressure of 5000 psi (350 bar), this element is designed for high-performance applications. The installation requires a valve hex size of 1-1/8 inches (28.6 mm) and should be torqued between 45 to 50 lbf ft (61 to 68 Nm). Additionally, it fits into the T5A cavity series and comes with a Viton seal kit for enhanced sealing capabilities. This filter element plays an essential role in maintaining system cleanliness and preventing sudden failures, ensuring smooth and efficient operation of hydraulic systems.
The Sun Hydraulics FLFAXDV (FLFAXDV) is a highly specialized filter element designed for hydraulic systems, providing crucial protection against errant particles that may bypass the main system filter or result from component failures. This Surface Type Last Chance element features a 304 stainless steel mesh media, with all internal components also made of 304 stainless steel, ensuring durability and longevity. The filter has a nominal rating of 40 microns and an absolute rating of 63 microns, making it effective in capturing fine particles. The differential crush pressure is rated at 3000 psid (210 bar), demonstrating its robustness under high-pressure conditions. The flow path is strictly from Port 2 to Port 1, and it should not be reversed even with a reverse free flow check valve installed. This ensures optimal performance and protection for the entire valve stack when installed directly above the subplate. With a capacity of handling up to 20 gpm (80 L/min) and a maximum operating pressure of 5000 psi (350 bar), this element is designed for high-performance applications. The installation requires a valve hex size of 1-1/8 inches (28.6 mm) and should be torqued between 45 to 50 lbf ft (61 to 68 Nm). Additionally, it fits into the T5A cavity series and comes with a Viton seal kit for enhanced sealing capabilities. This filter element plays an essential role in maintaining system cleanliness and preventing sudden failures, ensuring smooth and efficient operation of hydraulic systems.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
| Cavity | T-5A |
| Series | 2 |
| Capacity | 20 gpm80 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-203-006 |
