SUN HYDRAULICS
FLHAXAN
$229.34 USD
- SUN HYDRAULICS
- Material:FLHAXAN
- Model:FLHA-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLHAXAN (Material Number: FLHAXAN) is a high-performance filter element designed to protect hydraulic systems from particulate contamination. This filter element is available in both Surface Type Last Chance and Depth Style configurations, ensuring versatility for various system requirements. The flow path is strictly Port 2 to Port 1, and it should not be reversed, even with a reverse free flow check valve installed. The Surface Type element features a 304 stainless steel mesh media, providing a nominal filtration rating of 40 microns and an absolute rating of 63 microns. It effectively captures errant particles that may bypass the main system filter or result from component failure. Depth Type elements are available in 3, 10, and 25-micron nominal ranges, utilizing pleated microglass media with clear zinc-coated components for enhanced durability. The FLHAXAN filter element is engineered to withstand a differential crush pressure of up to 3000 psid (210 bar), making it suitable for high-pressure applications with a maximum operating pressure of 5000 psi (350 bar). It is designed for installation directly above the subplate to protect the entire valve stack from contaminants. This placement ensures that the filter remains unobtrusive during regular operation while providing critical protection against sudden component failures. Cartridges with EPDM seals are specifically intended for use in systems utilizing phosphate ester fluids; exposure to petroleum-based fluids can damage these seals. The Sun Hydraulics FLHAXAN also offers a capacity of up to 40 gpm (160 L/min) and requires an installation torque between 150-160 lbf ft (203-217 Nm). With its robust construction and reliable performance, this filter element is an essential component for maintaining the cleanliness and longevity of hydraulic systems.
The Sun Hydraulics FLHAXAN (Material Number: FLHAXAN) is a high-performance filter element designed to protect hydraulic systems from particulate contamination. This filter element is available in both Surface Type Last Chance and Depth Style configurations, ensuring versatility for various system requirements. The flow path is strictly Port 2 to Port 1, and it should not be reversed, even with a reverse free flow check valve installed. The Surface Type element features a 304 stainless steel mesh media, providing a nominal filtration rating of 40 microns and an absolute rating of 63 microns. It effectively captures errant particles that may bypass the main system filter or result from component failure. Depth Type elements are available in 3, 10, and 25-micron nominal ranges, utilizing pleated microglass media with clear zinc-coated components for enhanced durability. The FLHAXAN filter element is engineered to withstand a differential crush pressure of up to 3000 psid (210 bar), making it suitable for high-pressure applications with a maximum operating pressure of 5000 psi (350 bar). It is designed for installation directly above the subplate to protect the entire valve stack from contaminants. This placement ensures that the filter remains unobtrusive during regular operation while providing critical protection against sudden component failures. Cartridges with EPDM seals are specifically intended for use in systems utilizing phosphate ester fluids; exposure to petroleum-based fluids can damage these seals. The Sun Hydraulics FLHAXAN also offers a capacity of up to 40 gpm (160 L/min) and requires an installation torque between 150-160 lbf ft (203-217 Nm). With its robust construction and reliable performance, this filter element is an essential component for maintaining the cleanliness and longevity of hydraulic systems.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Cartridges with EPDM seals are for use in systems with phosphate ester fluids. Exposure to petroleum based fluids, greases and lubricants will damage the seals.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
| Cavity | T-16A |
| Series | 3 |
| Capacity | 40 gpm160 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/4 in.31,8 mm |
| Valve Installation Torque | 150 - 160 lbf ft203 - 217 Nm |
| Seal kit - Cartridge | Viton: 990-016-006 |
