SUN HYDRAULICS
FLJAXAN
$279.87 USD
- SUN HYDRAULICS
- Material:FLJAXAN
- Model:FLJA-XAN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXAN (FLJAXAN) is a high-performance filter element designed to protect hydraulic systems from particulate contamination. This product is available in two types: Surface Type Last Chance and Depth Style, each serving specific filtration needs within hydraulic systems. The Surface Type features a 304 stainless steel mesh media with a nominal rating of 40 microns and an absolute rating of 63 microns, ideal for capturing particles that may bypass the main system filter or result from component failure. It is engineered to withstand high collapse pressures, with a differential crush pressure of 3000 psid (210 bar), ensuring durability under demanding conditions. The flow path for the FLJAXAN is strictly from Port 2 to Port 1, and it should not be reversed, even if a reverse free flow check valve is installed. This configuration helps maintain optimal filtration efficiency and system protection. Installation directly above the subplate enhances its ability to safeguard the entire valve stack from contaminants. For more intensive filtration requirements, the Depth Type elements are available in three nominal ranges: 3 microns, 10 microns, and 25 microns. These feature pleated microglass media with clear zinc-coated components, offering superior particle retention as indicated by their Beta ratios in performance curves. The FLJAXAN is compatible with T18A cavity series valves and supports a capacity of up to 80 gpm (320 L/min) at a maximum operating pressure of 5000 psi (350 bar). The installation requires precise torque specifications between 350-375 lbf ft (475-508 Nm), using Viton seal kits for reliable sealing performance. With its robust design and adaptability, this filter element ensures prolonged operational life and reliability of hydraulic systems by effectively managing contamination risks.
The Sun Hydraulics FLJAXAN (FLJAXAN) is a high-performance filter element designed to protect hydraulic systems from particulate contamination. This product is available in two types: Surface Type Last Chance and Depth Style, each serving specific filtration needs within hydraulic systems. The Surface Type features a 304 stainless steel mesh media with a nominal rating of 40 microns and an absolute rating of 63 microns, ideal for capturing particles that may bypass the main system filter or result from component failure. It is engineered to withstand high collapse pressures, with a differential crush pressure of 3000 psid (210 bar), ensuring durability under demanding conditions. The flow path for the FLJAXAN is strictly from Port 2 to Port 1, and it should not be reversed, even if a reverse free flow check valve is installed. This configuration helps maintain optimal filtration efficiency and system protection. Installation directly above the subplate enhances its ability to safeguard the entire valve stack from contaminants. For more intensive filtration requirements, the Depth Type elements are available in three nominal ranges: 3 microns, 10 microns, and 25 microns. These feature pleated microglass media with clear zinc-coated components, offering superior particle retention as indicated by their Beta ratios in performance curves. The FLJAXAN is compatible with T18A cavity series valves and supports a capacity of up to 80 gpm (320 L/min) at a maximum operating pressure of 5000 psi (350 bar). The installation requires precise torque specifications between 350-375 lbf ft (475-508 Nm), using Viton seal kits for reliable sealing performance. With its robust design and adaptability, this filter element ensures prolonged operational life and reliability of hydraulic systems by effectively managing contamination risks.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
