SUN HYDRAULICS
FLJAXAV
$286.32 USD
- SUN HYDRAULICS
- Material:FLJAXAV
- Model:FLJA-XAV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXAV (Material Number: FLJAXAV) is a specialized filter element designed for hydraulic systems, offering robust protection against errant particles that may bypass the main system filter or result from component failures. This product features a Surface Type Last Chance element, utilizing a 304 stainless steel mesh media with all internal components also made from 304 stainless steel, ensuring durability and reliability. The filter has a nominal rating of 40 microns and an absolute rating of 63 microns, making it highly effective in capturing fine contaminants. The flow path is strictly from Port 2 to Port 1, and reverse flow is not recommended even if a reverse free flow check valve is installed. With a differential crush pressure of 3000 psid (210 bar), the FLJAXAV can withstand high collapse pressures. This filter element is designed to be installed directly above the subplate, providing protection to the entire valve stack from potentially damaging particles. It operates efficiently within systems with an operating capacity of up to 80 gpm (320 L/min) and can handle maximum pressures of up to 5000 psi (350 bar). The installation requires a torque specification of between 350 - 375 lbf ft (475 - 508 Nm), and it fits into cavity T18A as part of Series 4. Sun Hydraulics' FLJAXAV is suitable for applications where maintaining system cleanliness is crucial for operational reliability, particularly in environments susceptible to sudden component failures. Its robust construction ensures that when integrated correctly into a hydraulic system, it provides unnoticed yet critical protection during regular operations.
The Sun Hydraulics FLJAXAV (Material Number: FLJAXAV) is a specialized filter element designed for hydraulic systems, offering robust protection against errant particles that may bypass the main system filter or result from component failures. This product features a Surface Type Last Chance element, utilizing a 304 stainless steel mesh media with all internal components also made from 304 stainless steel, ensuring durability and reliability. The filter has a nominal rating of 40 microns and an absolute rating of 63 microns, making it highly effective in capturing fine contaminants. The flow path is strictly from Port 2 to Port 1, and reverse flow is not recommended even if a reverse free flow check valve is installed. With a differential crush pressure of 3000 psid (210 bar), the FLJAXAV can withstand high collapse pressures. This filter element is designed to be installed directly above the subplate, providing protection to the entire valve stack from potentially damaging particles. It operates efficiently within systems with an operating capacity of up to 80 gpm (320 L/min) and can handle maximum pressures of up to 5000 psi (350 bar). The installation requires a torque specification of between 350 - 375 lbf ft (475 - 508 Nm), and it fits into cavity T18A as part of Series 4. Sun Hydraulics' FLJAXAV is suitable for applications where maintaining system cleanliness is crucial for operational reliability, particularly in environments susceptible to sudden component failures. Its robust construction ensures that when integrated correctly into a hydraulic system, it provides unnoticed yet critical protection during regular operations.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
