SUN HYDRAULICS
FLJAXBN
$279.87 USD
- SUN HYDRAULICS
- Material:FLJAXBN
- Model:FLJA-XBN
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXBN (Material Number: FLJAXBN) is a high-performance filter element designed for hydraulic systems, featuring a surface type last chance and depth style elements. The flow path is strictly from Port 2 to Port 1, ensuring optimal filtration and system protection, and should not be reversed even with a reverse free flow check valve installed. Constructed with 304 stainless steel mesh media and internal components, the surface type element offers a 40-micron nominal rating and a 63-micron absolute rating, efficiently capturing errant particles that might bypass the main system filter or result from component failure. This robust element can handle differential crush pressures up to 3000 psid (210 bar), making it suitable for demanding applications. The filter's installation directly above the subplate safeguards the entire valve stack from contaminants. Additionally, depth type elements are available with pleated microglass media in 3 m, 10 m, and 25 m nominal ranges, providing versatile options for different filtration needs. With a cavity size of T18A and a series capacity of up to 80 gpm (320 L/min), this filter element supports high-flow applications while operating at pressures up to 5000 psi (350 bar). The valve hex size is 1-5/8 inches (41.3 mm), requiring an installation torque between 350 - 375 lbf ft (475 - 508 Nm). For maintenance purposes, Viton seal kits are available under cartridge part number: 990018006. The Sun Hydraulics FLJAXBN ensures reliable operation by protecting hydraulic systems from unexpected component failures and maintaining cleanliness levels essential for efficient performance.
The Sun Hydraulics FLJAXBN (Material Number: FLJAXBN) is a high-performance filter element designed for hydraulic systems, featuring a surface type last chance and depth style elements. The flow path is strictly from Port 2 to Port 1, ensuring optimal filtration and system protection, and should not be reversed even with a reverse free flow check valve installed. Constructed with 304 stainless steel mesh media and internal components, the surface type element offers a 40-micron nominal rating and a 63-micron absolute rating, efficiently capturing errant particles that might bypass the main system filter or result from component failure. This robust element can handle differential crush pressures up to 3000 psid (210 bar), making it suitable for demanding applications. The filter's installation directly above the subplate safeguards the entire valve stack from contaminants. Additionally, depth type elements are available with pleated microglass media in 3 m, 10 m, and 25 m nominal ranges, providing versatile options for different filtration needs. With a cavity size of T18A and a series capacity of up to 80 gpm (320 L/min), this filter element supports high-flow applications while operating at pressures up to 5000 psi (350 bar). The valve hex size is 1-5/8 inches (41.3 mm), requiring an installation torque between 350 - 375 lbf ft (475 - 508 Nm). For maintenance purposes, Viton seal kits are available under cartridge part number: 990018006. The Sun Hydraulics FLJAXBN ensures reliable operation by protecting hydraulic systems from unexpected component failures and maintaining cleanliness levels essential for efficient performance.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
Show FAQ
