SUN HYDRAULICS
FLJAXBV
$286.32 USD
- SUN HYDRAULICS
- Material:FLJAXBV
- Model:FLJA-XBV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXBV (Material Number: FLJAXBV) is a high-performance filter element designed for hydraulic systems. This product features a Surface Type Last Chance element, constructed with 304 stainless steel mesh media and internal components, offering a 40-micron nominal rating and 63-micron absolute. It is engineered to capture stray particles that might bypass the main system filter or result from component failures, ensuring enhanced protection. The flow path is strictly from Port 2 to Port 1, and it should not be used in reverse, even with a reverse free flow check valve installed. This filter element has a differential crush pressure of 3000 psid (210 bar) and is intended for in-line use within the system, directly above the subplate to safeguard the entire valve stack from contaminants. Additionally, Depth Type elements are available with pleated microglass media and clear zinc-coated components in nominal ranges of 3 m, 10 m, and 25 m. These elements have specific Beta ratios as detailed in performance curves. The FLJAXBV model fits into Cavity T18A of Series 4 and supports a capacity of up to 80 gpm (320 L/min) with a maximum operating pressure of 5000 psi (350 bar). The valve hex size measures at 1-5/8 inches (41.3 mm), with an installation torque range between 350-375 lbf-ft (475-508 Nm). For maintenance purposes, it uses Viton seal kits identified by cartridge number 990018006. This Sun Hydraulics filter element ensures reliability by providing unobtrusive operation under normal conditions while offering vital protection during unexpected component failures.
The Sun Hydraulics FLJAXBV (Material Number: FLJAXBV) is a high-performance filter element designed for hydraulic systems. This product features a Surface Type Last Chance element, constructed with 304 stainless steel mesh media and internal components, offering a 40-micron nominal rating and 63-micron absolute. It is engineered to capture stray particles that might bypass the main system filter or result from component failures, ensuring enhanced protection. The flow path is strictly from Port 2 to Port 1, and it should not be used in reverse, even with a reverse free flow check valve installed. This filter element has a differential crush pressure of 3000 psid (210 bar) and is intended for in-line use within the system, directly above the subplate to safeguard the entire valve stack from contaminants. Additionally, Depth Type elements are available with pleated microglass media and clear zinc-coated components in nominal ranges of 3 m, 10 m, and 25 m. These elements have specific Beta ratios as detailed in performance curves. The FLJAXBV model fits into Cavity T18A of Series 4 and supports a capacity of up to 80 gpm (320 L/min) with a maximum operating pressure of 5000 psi (350 bar). The valve hex size measures at 1-5/8 inches (41.3 mm), with an installation torque range between 350-375 lbf-ft (475-508 Nm). For maintenance purposes, it uses Viton seal kits identified by cartridge number 990018006. This Sun Hydraulics filter element ensures reliability by providing unobtrusive operation under normal conditions while offering vital protection during unexpected component failures.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
