SUN HYDRAULICS
FLJAXCV
$286.32 USD
- SUN HYDRAULICS
- Material:FLJAXCV
- Model:FLJA-XCV
- Summary:Cartridge
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics FLJAXCV (Material Number: FLJAXCV) is a high-performance filter element designed for hydraulic systems, offering robust protection against particulate contamination. This product is available in Surface Type Last Chance and Depth Style configurations, each tailored to specific filtration needs. The Surface Type element features a 304 stainless steel mesh media with a 40-micron nominal rating and is designed to capture particles that may bypass the main system filter or arise from component failures. The Depth Type elements utilize pleated microglass media and are available in 3, 10, and 25-micron ranges for more precise filtration requirements. Designed for inline installation, the FLJAXCV ensures that the flow path is strictly from Port 2 to Port 1, with a differential crush pressure of up to 3000 psid (210 bar). Its construction supports high collapse pressure applications, making it suitable for demanding environments. The filter can handle a capacity of up to 80 gpm (320 L/min) and withstands maximum operating pressures of 5000 psi (350 bar). Installation directly above the subplate offers comprehensive protection for the entire valve stack from contaminants. The product's robust build includes all internal components made of durable 304 stainless steel. For secure installation, it requires a torque specification between 350-375 lbf ft (475-508 Nm), fitting into a T18A cavity with a valve hex size of 1-5/8 inches (41.3 mm). Seal integrity is maintained using Viton material, ensuring reliable performance under various operational conditions. The Sun Hydraulics FLJAXCV filter element stands out as a reliable choice for maintaining hydraulic system cleanliness and preventing sudden component failures due to contamination.
The Sun Hydraulics FLJAXCV (Material Number: FLJAXCV) is a high-performance filter element designed for hydraulic systems, offering robust protection against particulate contamination. This product is available in Surface Type Last Chance and Depth Style configurations, each tailored to specific filtration needs. The Surface Type element features a 304 stainless steel mesh media with a 40-micron nominal rating and is designed to capture particles that may bypass the main system filter or arise from component failures. The Depth Type elements utilize pleated microglass media and are available in 3, 10, and 25-micron ranges for more precise filtration requirements. Designed for inline installation, the FLJAXCV ensures that the flow path is strictly from Port 2 to Port 1, with a differential crush pressure of up to 3000 psid (210 bar). Its construction supports high collapse pressure applications, making it suitable for demanding environments. The filter can handle a capacity of up to 80 gpm (320 L/min) and withstands maximum operating pressures of 5000 psi (350 bar). Installation directly above the subplate offers comprehensive protection for the entire valve stack from contaminants. The product's robust build includes all internal components made of durable 304 stainless steel. For secure installation, it requires a torque specification between 350-375 lbf ft (475-508 Nm), fitting into a T18A cavity with a valve hex size of 1-5/8 inches (41.3 mm). Seal integrity is maintained using Viton material, ensuring reliable performance under various operational conditions. The Sun Hydraulics FLJAXCV filter element stands out as a reliable choice for maintaining hydraulic system cleanliness and preventing sudden component failures due to contamination.
Sun filter elements are available as Surface Type (Last Chance) and Depth Style elements. The flow path is Port 2 to Port 1 and should not be used in reverse, even with a reverse free flow check valve installed. The elements have a high collapse pressure and are intended to be used in line with the system. Filter life will depend on initial system cleanliness and the amount of dirt ingression to the system when operating.
- Differential crush pressure is 3000 psid (210 bar).
- The flow path is Port 2 to Port 1 only.
- Installation directly above the subplate will protect the entire valve stack from particles.
- Surface type element features a 304 stainless steel mesh media. All internal components are 304 stainless steel.
- Surface Type elements have a 40 micron nominal rating (63 micron absolute).
- Surface Type elements are designed to capture errant particles that may not be trapped in the main system filter or particles resulting from a component failure.
- With a correctly assembled system, Surface Type elements will be unnoticed during regular operation, but will provide protection from sudden component failure.
- Surface Type (Last Chance) elements have a single layer stainless steel mesh supported by perforated sheet tube.
- Depth Type elements feature a pleated microglass media with clear zinc coated components.
- Depth type elements are available in 3 µm, 10 µm, and 25 µm nominal ranges.
- 3, 10, and 25 micron elements have a Beta ratio as shown in the Performance Curves tab.
| Cavity | T-18A |
| Series | 4 |
| Capacity | 80 gpm320 L/min. |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft475 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-018-006 |
